Description

ZDMS0.8 Automatic Fire Monitor

water monitor are often combined with a Thermal Fire Detection system. This operates by scanning the area for infra-red radiation, which it can then convert into a temperature reading. When a set temperature threshold is reached, the fire alarm is activated and signals relayed to the cannon.

The signals received by the cannon include details of the zone in which the fire has been detected. This provides the cannon the information on the area to concentrate the suppression, and the water cannon, mounted on a motorised chassis with a self-aligning system, turns and directs the water jet directly at the risk area identified by the detection system.This targeted approach ensures that the risk is dealt with swiftly and efficiently and minimises clean up costs.

Detailed Image

Dimensions as below:

Rotation Angle:

Specification

ZDMS0.8 Automatic Fire Monitor
Model	ZDMS0.8 /20s-w	ZDMS0.8/30s-w
Control	Automatic,Control box,Field manual	Automatic,Control box,Field manual
Rated Flow	1200 LPM	1800 LPM
Working Pressure	8 Bar	8 Bar
Jetting Radius	56 m	62 m
Max Protection Radius	50 m	55 m
Monitoring Radius	80 m
Horizontal Rotation Angle	360°
Vertical Rotation Angle	-90°~+30°
Mounting Height	8~15 m
Power Consumption	Monitoring 1W,Detecting 50W
Consumption Mode	RS485
Inlet	2.5''BS Flange,others size and astandard available
Detector type	Infrared ray＆UV sensor technology

Configuration List

Part Name	Quantity	Remarks
Automatic Fire Monitor	1
Control Box	1	Switch operation mode Automatic/Manual
Signal Decoder	1	Convert the signal into the information it represents
Solenoid Valve	1	Control fluid automation infrastructure components
Camera(optional)	1	Video Surveillance

Order Information

Dear Customer,
Before ordering, please contact with our sales team to discuss order information, such as Model Number, Flow Rate, Material, Control Ways, Package,Etc.
If you have any other requirements or wanna know more info about our products, welcome to contact as well. Our Sales team and Technical Department are willing to support you.
* Contacts: Email: sales3@forede.com  I  Tel/WhatsApp: 008618750582600 I  Wechat: 18750582600

FAQ                                                                                                                         Q:What about the lead time?
A:Sample needs 7-15 days, mass production time needs 30-40 weeks for order quantity more than 1 container.
Q:Where is your company?
A:NO. 1,Building 29#,B Zone,Chenghui International Trading Market,Xiamei Town,Nan'an City,Fujian Province,China.
Q:Can you accept OEM?
A:Yes, we do customized design for our clients.
