Description
Technical Parameters
Products Description
The truck-mounted water cannon is one of the most important equipment of fire water truck. It is mainly used for fire fighting, urban cleaning, road cooling, sand storm prevention, rescue and disaster relief and other large-scale activities.
Products Parameters
|
Model Number |
PSKD8/20W-CA | PSKD8/30W-CA | PSKD8/40W-CA | PSKD8/20-40W-CA |
|---|---|---|---|---|
| Flow Rate |
1200 LPM Constant Flow
|
1800 LPM Constant Flow | 2400 LPM Constant Flow |
1200-1800-2400 LPM Constant Flow |
|
Working Pressure |
14 Bar | |||
| Max. Reach | 50 meters | 60 meters | 65 meters | 50-65 meters |
| Max Range Of Motion |
-30°to+85° Vertically,340° Rotation,other degree available
|
|||
| Max.Fog Angle | 120° | |||
| Power Supply |
DC 24V is standard
|
|||
| Power Consumption |
≤200W ,Led Light 50W
|
|||
| Waterway Size |
2 1/2"(65mm)
|
|||
| Monitor Outlet |
2 1/2"(65mm)NH male thread
|
|||
| Monitor Inlet |
Flange2.5" ANSI 150# is standard,other size and standard available
|
|||
| Material |
Monitor&Nozzle-Hardcoatedanodizedaluminiumalloy
|
|||
| Control System |
VMCS-01
|
|||
monitor Description
How To Cooperate With Us?
Dear Customer, welcome to contact us
Our address
Nan'an City, Quanzhou City Fujian PRC-China
Phone Number
+86 177 5086 9603
sales7@forede.com
Hot Tags: Automatic Water Monitor Controller, China, manufacturers, suppliers, wholesale, price, Wireless Fire Water Monitor, Fire Sprinkler Head Cover Plate, Explosion Proof Fire Monitor, Fire Fighting Monitors, Remote Explosion Fire Monitor, Remote Water Monitor
Aluminium alloy construction,hard anodized;
Constant or Selectable flowrate;
Vertical travel of 115°,from-30°to+85°;
340° rotation horizontally;
Electric control jetting Pattern:Straight stream,Fog;
Electric.driver and control unitbox are waterproof;
Optional power supply 12V/24V DC(optional),or100-230AC.
