Product Introduction:
Explosion Proof Remote Control Fire Foam Monitor on Sale
Send Inquiry
Description
Technical Parameters
Technical Data
Flow
64 L/S ( 3840LPM )
80 L/S ( 4800LPM )
Working Pressure
0.8 Mpa
0.8 Mpa
Water Jet Range
≥70m
≥80m
Foam Jet Range
≥65m
≥75m
Elevation
-45°/+90°  ( the angle can customized )
Rotation
360°
Turning speed
24°/sec Rotation 10°/sec Vertical
power supply
12/24VDC or 100-380VAC
Power Consumption normal/Max
50W/150W
Cable Length Monitor- CPU
5m
Cable Length Joystick-CPU
5m standard/ other length available
Water way size
2.5 inch
PACKAGE
CARTON :  MONITOR, NOZZLE, CONTROL BOX, JOYSTICK, CABLES, WIRELESS CONTROL
Explosion Proof Level
Exd ⅡB T4 Gb
*More info please contact our sales team for help.
