Product Introduction:
Concealed sprinklers are suitable for installation in places with luxurious decoration and high appearance requirements, such as hotels, clubs, office buildings, entertainment centers, etc. It is also suitable for places where the ceiling elevation is too low due to installation, air conditioning, etc., and the headroom is limited, as well as places where there are dense crowds, cargo handling, etc., and may collide with the exposed nozzle at any time.
Send Inquiry
Description
Technical Parameters



K5.6 Concealed Fire Sprinkler For Fire Sprinkler System

Concealed sprinklers are suitable for installation in places with luxurious decoration and high appearance requirements, such as hotels, clubs, office buildings, entertainment centers, etc. It is also suitable for places where the ceiling elevation is too low due to installation, air conditioning, etc., and the headroom is limited, as well as places where there are dense crowds, cargo handling, etc., and may collide with the exposed nozzle at any time.



Model Number Style Size
Temperature
Response Type
ZSTDY 80-57°C Q5
Concealed
1/2" (DN15)
57°C
Standard
ZSTDY 80-68°C Q5
Concealed
1/2" (DN15)
68°C
Standard
ZSTDY 80-79°C Q5
Concealed
3/4" (DN20)
79°C
Standard
ZSTDY 80-93°C Q5
Concealed
3/4" (DN20)
93°C Standard
ZSTDY 80-141°C Q5 Concealed 3/4" (DN20) 141°C Standard





FAQ:



Q.Do you have warranty?

A:Yes, all products have one year warranty.



Q.What's your payment terms?

A:We accept T/T, L/C, Western Union, Paypal,etc.



Q:What can you buy from us?

Fire Sprinkler system,Foam system,Fire Monitor,Fire Nozzle,Fire Valves,Fire Hydrants



Q:Is the sample provided for free?

A few small products like sprinkler decorative covers can be provided for free, but the buyer needs to pay for the shipping. Other products need to be confirmed according to the specific situation.



Order Information:

Dear Customer,
Before ordering, please contact with our sales team to discuss order information, such as Model Number, Flow Rate, Material, Control Ways, Package,Etc.
If you have any other requirements or wanna know more info about our products, welcome to contact as well. Our Sales team and Technical Department are willing to support you.


* Contacts: Email: sales4@forede.com I Tel/WhatsApp: 008618750638978 I Wechat: 18750638978



Related Products

Standard Spray Sprinklers
Standard Spray Sprinkelrs
9C3467E0BE3FC30AC1E1640EE3429FE4
Storage Sprinklers
Extended Coverage Sprinklers
Extended Coverage Sprinklers
Dry Sprinklers
Dry Sprinklers
63AF01AE896D0394FFEB4284C0FCDB94
Concealed Sprinklers
EEB252FE5733DCFB325133D2DC1DE252
Spray Nozzles
Sprinkler Accessories2
Sprinkler Accessories







Hot Tags: concealed fire sprinkler head, China, manufacturers, suppliers, wholesale, price, Medium Velocity Water Spray, Brass High Velocity Type Spray Nozzles, Water Curtain Nozzle Fire Fighting, Impact Fire Sprinkler For Fire Fighting, High Velocity Type Water Spray Nozzle, Sidewall Water Spray Nozzle

Features

K FACTOR:K 5.6@ US(80@Metric)/K 8.0@ US (161@Metric)

Thread Size:DN15 (1/2''), DN20(3/4'')

Connecting Thread: BSP (NPT Optional)

Main Material: Brass

Sensitive Element: GDGIIX® Brand Glass Bulb

Seal Material: NBR

Surface Finishing :Natural Brass.
