Material | Frame | Brass | ||||
Button | Brass | |||||
Compression Screw | Brass | |||||
Deflector | Brass | |||||
Sensitive Element | Glass Bulb | |||||
K Factor | 8.0@US(115@Metric) | 11.2@US(160@Metric) | ||||
Connecting Size | DN20(3/4”) | |||||
Response Type | Quick Response | |||||
Glass Bulb Size | Ø3mm | |||||
Glass Bulb Brand | JOB | |||||
Temp. Rating | 57°C | 68°C | 79°C | 93°C | 141°C | |
Glass Bulb Color | Orange | Red | Yellow | Green | Blue | |
Connecting Thread | BSP(NPT Optional) | |||||
Installation Type | Upright/Pendent/Sidewall | |||||
Surface Finishing | Chrome | |||||
Hot Tags: extended coverage quick response fire sprinklers, China, manufacturers, suppliers, wholesale, price, Extended Coverage Glass Bulb Fire Sprinklers, Extended Coverage Standard Response Sprinklers, Water Spray Nozzle, Fire Hose Monitor
1)The protection area is larger than the ordinary sprinkler head
2) 3mm JOB glass ball, faster response time and safer
