Products Description
Self Educting Handline Nozzle
ZPQD Self Educting Handline Nozzle is a specially designed nozzle used in firefighting that produces a high-quality foam. It is called "self-educating" because it automatically adjusts the foam's mixture ratio based on the water pressure and flow, without the need for an external eductor or proportioner. This means that the nozzle is able to produce foam in a variety of flow rates and pressures, making it a versatile tool in fire suppression.
Features:
- Handle Type: Pistol Grip Type;
- Body Material: Hard Anodized Aluminum;
- Valve Material: ABS Ball valve;
- Handle Material: Horseshoe (Injection Molded Nylon );
- Foam Inspiration Tube Material: SS304 Stainless Steel;
- 25% Liquid Precipitation Time: ≥ 120 S;
- Foam Expansion: ≥ 5 Times
- Foam Proportion: OFF-0.25%-0.5%-1%-3%-6% adjustable
- Coupling: DN40 (1.5"), DN50 (2"), DN65 (2.5"); STORZ, NH, John Morris,GOST, Machino,etc.
Water Available
Foam Expansion
Flow Rate
Warranty
Specification
|
Material |
Foam Inspiration Tube |
SS304 Stainless Steel | |
| Handle | Horseshoe(Injection Molded Nylon) | ||
|
Valve |
ABS Ball valve or Aluminium valve optional | ||
|
Body |
Hard Anodized Aluminium Alloy | ||
|
Model |
ZPQD8-40 |
ZPQD8-50 | ZPQD8-65 |
|
Flow Rate |
400LPM |
400LPM | 400LPM |
| Working Pressure | 0.7MPa | ||
|
Jetting Range |
≥28m |
≥28m | ≥28m |
|
Foam Expansion |
≥ 5 times |
||
|
Connecting Inlet |
1.5''(DN40), 2''(DN50),2.5''(DN65) |
||
Frequently Asked Question
Frequently Asked Questions
Q: What's the MOQ of your products?
-
A :Our MOQ is one (1) piece/set.
Q: How long is the delivery time?
-
A :Usually around 15 days after payment.
Q: Can you accept OEM?
-
A:Yes, we do customized design for our clients.
Q: What's your payment terms?
-
A: We accept T/T, L/C, Western Union, Paypal,etc.
Q. Do you have warranty?
-
A: Yes, all products have one year warranty.
Recommend Product
Our Main Product
Nozzles
Monitors
Foam System
General Valves
Hydrant System
Gas Suppression System
Contact Information
Dear Customer,
Before ordering, please contact with our sales team to discuss order information, such as Model Number, Flow Rate, Material, Control Ways, Package,Etc.
If you have any other requirements or wanna know more info about our products, welcome to contact as well. Our Sales team and Technical Department are willing to support you.
Our address
Nan'an City, Quanzhou City Fujian PRC-China
