Saddle Type Water Flow Indicator

Saddle Type Water Flow Indicator
Product Introduction:
Water flow indicator is a device used to specify the direction and rate of flow of water through a system. They are commonly used within sprinkler systems as a means of triggering local fire alarms and/or alerting the local firefighting department of a probable fire.
Send Inquiry
Description
Technical Parameters
Products Description



Saddle type water flow indicator is part of the automatic sprinkler system. Using the spray pipe network in the inland waters flow pushing blade, touch the micro switch, so as to convert current signal into electrical signal connected to the controller to start the automatic fire alarm system is a kind of alarm devices, and can be used to detect the automatic sprinkler system and to determine the fire area. Risk is widely used for medium and light construction water level blazes hotels, shopping malls, restaurants, entertainment venues, hospitals, office buildings and factories, warehouses and other places.



ZSJZ/A saddle type water flow indicator is a kind of alarm equipment which converts water flow signal to electric signal in the automatic sprinkler system. It is usually installed on the horizontal pipe, and used to detect the system operation condition and show the fire area.



Products Parameters

Model Number
Size
Voltage
Working Pressure
ZSJZ/A 50
DN50(2")
DC24V,0.5-1.0A
1.2Mpa
ZSJZ/A 65
DN65(2.5")
DC24V,0.5-1.0A
1.2Mpa
ZSJZ/A 80
DN80(3")
DC24V,0.5-1.0A
1.2Mpa
ZSJZ/A 100
DN100(4")
DC24V,0.5-1.0A
1.2Mpa
ZSJZ/A 125
DN125(5")
DC24V,0.5-1.0A
1.2Mpa
ZSJZ/A 150
DN150(6")
DC24V,0.5-1.0A
1.2Mpa
ZSJZ/A 200
DN200(8")
DC24V,0.5-1.0A
1.2Mpa
ZSJZ/A 250
DN250(10")
DC24V,0.5-1.0A
1.2Mpa



FAQ



Q:Can I have a sample order?

A:Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.



Q: How do you deliver the goods and how long does it take to arrive?

A:We usually deliver mass order by sea and air, delivery time is depended on the carrier,urgent trail order usually deliver by DHL, UPS, FedEx or TNT. It usually takes 5-7 days to arrive. Railway also optional. In fact, the delivery method depends on the quantity.



Q:Is it OK to OEM ?

A:A: Yes. Please inform us formally before our production and confirm the design and other requirements firstly .





Hot Tags: saddle type water flow indicator, China, manufacturers, suppliers, wholesale, price
