Flange Alarm Check Valve With Stainless Steel Pipe

Flange Alarm Check Valve With Stainless Steel Pipe
Product Introduction:
forede Flange Alarm Check Valve With Stainless Steel Pipe is a one-way valve that only allows water to flow into the sprinkler system in one direction and alarms at a specified flow rate. The wet alarm valve usually equals the water pressure before and after the valve disc (the water passes through the water pressure balance hole in the guide pipe to keep the water pressure balance before and after the valve disc).
Send Inquiry
Description
Technical Parameters

The Induction of Flange Alarm Check Valve With Stainless Steel Pipe

forede Flange Alarm Check Valve With Stainless Steel Pipe is a one-way valve that only allows water to flow into the sprinkler system in one direction and alarms at a specified flow rate. The wet alarm valve usually equals the water pressure before and after the valve disc (the water passes through the water pressure balance hole in the guide pipe to keep the water pressure balance before and after the valve disc).


The Specification of Flange Alarm Check Valve With Stainless Steel Pipe

Material

BodyDuctile Iron
Clab304 stainless steel with NBR
Pipes304 stainless steel
Ball Valve&StrainerBrass

Retard Chamber

304 stainless steel
Water Motor Gong304 stainless steel
Working Pressure
16 bar
Applicable Temperature4°C to 70 °C
InstallationVertically
Flow Switch Contact CapacityDC 24V ,5A
ConnectionFlange x Flange
Available SizeDN80 thru DN250


The FAQ of Flange Alarm Check Valve With Stainless Steel Pipe


Q1:What is the customs code of the Flange Alarm Check Valve With Stainless Steel Pipe?
the customs code of Flange Alarm Check Valve With Stainless Steel Pipe is 8481804090.


Q2: How long does Flange Alarm Check Valve With Stainless Steel Pipe take to produce ?

Flange Alarm Check Valve With Stainless Steel Pipe quantity between 4 sets can be produced within 15 days. The specific production time needs to have specific products and product quantities to confirm.

Q3:How to mail the samples of Flange Alarm Check Valve With Stainless Steel Pipe ?

Small quantity of Flange Alarm Check Valve With Stainless Steel Pipe are usually sent by express (DHL, UPS, FEDEX, TNT) or air. If the buyer has other opinions, both parties can discuss with each other



Hot Tags: flange alarm check valve with stainless steel pipe, China, manufacturers, suppliers, wholesale, price, Galvanized Type Alarm Check Valve, Groove Type Alarm Check Valve, Groove Type Alarm Valve, Grooved Wet Type Alarm Valve, Fire Signal Butterfly Valve, Foot Type Valve With Strainer

1) Ductile iron construction valve body,less weight and extra strength.

2) Easy maintenance just require to disassemble the valve cover .

3) The all moving parts can be serviced without removing the valve from the installed position.

4) Simple design for easy installation and operation.

5) Vertical installation.

6) CCCF certificated.
