Flange End NRS Gate Valve For Fire Fighitng

Product Introduction:

NRS Water Gate Valve is also called rotating stem gate valve (also called dark stem wedge gate valve). The valve stem nut is set on the gate. The rotation of the handwheel drives the rotation of the valve stem to lift the gate. Usually there is a trapezoidal thread at the bottom end of the valve stem. The thread on the bottom end of the valve and the guide groove on the disc will rotate the gate. It becomes linear motion, that is, the operating torque is changed to operating thrust.

Send Inquiry

Description

Technical Parameters

Production

Z45X Flanged Non-Rising Steam Stem Gate Valve is a type of valve that is primarily used to regulate the flow of fluids such as water, gas, and steam in pipelines. This type of valve is designed with flanged ends, which allow it to be easily bolted to other components in the pipeline system. The non-rising stem feature means that the stem does not move up and down when the valve is operated, which makes it particularly suitable for use in tight spaces. Other features of a flange end non-rising stem gate valve include a cast iron body, a metal-seated gate, and a handwheel or gear-operated mechanism for adjusting the flow of fluid. This type of valve is commonly used in industrial applications, oil and gas, water and wastewater treatment, and plumbing systems.

Specification

Model	Inch	mm	Connection	Valve Type	Working pressure	Color
Z45-16Q-50	2	50	Flange End	NRS	1.0/1.6Mpa	Red/Blue
Z45-16Q-65	2.5	65	Flange End	NRS	1.0/1.6Mpa	Red/Blue
Z45-16Q-80	3	80	Flange End	NRS	1.0/1.6Mpa	Red/Blue
Z45-16Q-100	4	100	Flange End	NRS	1.0/1.6Mpa	Red/Blue
Z45-16Q-125	5	125	Flange End	NRS	1.0/1.6Mpa	Red/Blue
Z45-16Q-150	6	150	Flange End	NRS	1.0/1.6Mpa	Red/Blue
Z45-16Q-200	8	200	Flange End	NRS	1.0/1.6Mpa	Red/Blue
Z45-16Q-250	10	250	Flange End	NRS	1.0/1.6Mpa	Red/Blue
Z45-16Q-300	12	300	Flange End	NRS	1.0/1.6Mpa	Red/Blue
Z45-16Q-350	14	350	Flange End	NRS	1.0/1.6Mpa	Red/Blue

FAQ:

Q:Can you accept OEM?

A:Yes, we do customized design for our clients.

Q: What's the MOQ of your products?

A:Our MOQ is one (1) piece/set.

Q:What about the lead time?

A:Sample needs 7-15 days, mass production time needs 30-40 weeks for order quantity more than 1 container.
