Rising Stem Flanged Type Gate Valve

Product Introduction:

Rising Stem Flange Gate Valve is exposed, and the nut is close to the handwheel and is fixed (not rotating or moving axially). The gate is lifted by rotating the screw, and the screw and the gate only have relative rotational movement. Relative axial displacement, the appearance is a gate-shaped bracket.

Send Inquiry

Description

Technical Parameters

Production

Rising Stem Flanged Type Gate Valve is a type gate valve which connect by flange.

Specification

Material	Body	Ductile Iron,QT450
	Seal	Ductile Iron,QT450 Cover by NBR
	Stem	2CR13 Stainless Steel
	Support	Ductile Iron,QT450
Working Pressure	16 bar
End Connections	Flange x Flange
Flange	BS4504 / ANSI150LB
Size	DN50
Valve Type	OSY Gate Valve

FAQ:

Q:Do you have a export licence?

Yes.

Q:Do you have after-sale service?

Yes, Good after-sale service, handling the customer complaint and solve problem for customers.

Hot Tags: rising stem flanged type gate valve, China, manufacturers, suppliers, wholesale, price, NRS Flanged Type Gate Valves, Rising Stem Flanged End Gate Valve, Fire Flange End Signal Gate Valve, Rising Stem Grooved Type Gate Valve, Wet Type Alarm Valve, Flanged Underground Gate Valve

1) Connect By Flange<br>

2)Simple shape, good manufacturing technology, wide range of applications<br>

3)Fluid resistance is small, the sealing surface by the medium of the brush and erosion is small<br>
