ZDMS series automatic fire extinguisher system devices once fire happened,system would be activated,scanned the fire horizontally and Vertically, located the fire source,control unit givedfire signal, in the same time, activated the fire pump, opened the valve, the monitor aimed at the fire source and jetted water or foam to put out the fire.
After put out the fire, the control unit gived signal to stop water jetting and returned to ready situation.any new fire sources would activate the system until all fire sources were put out.
|
Vertical Rotation Angle
|
-90°~+30°
|
|
|
Detector Type
|
Infrared ray&UV sensor technology
|
|
|
Size
|
DN65(2.5'') BS ,other size and standard avaliable
|
|
|
Installation
|
Hanging, Mounting
|
|
|
Part Name
|
Quantity
|
Remarks
|
|
ZDMS0.8 EXAutomatic Fire Monitor
|
1
|
|
|
EX-Control Unit
|
1
|
Switch operation mode Automatic/Manual
|
|
EX-Connecting Box
|
1
|
Connecting Wiring
|
|
EX-UV Detector
|
1
|
Detect fire, activate devices
|
|
EX-Camera(optional)
|
1
|
Video Surveillance
|
|
EX-Electric Valve(optional)
|
1
|
Opening and closing water supply
|
Q:Is the sample provided for free?
A:A few small products like sprinklers decorative covers can be provided for free, but buyers pay for freight. Other products need to be confirmed.
Q:What is the production time of the sample?
A:Generally speaking, it isn't a large-scale purchase, and the lead time about 15 working days.Of course, having an urgent order, please reconfirm with us.
Q:How to mail the samples?
A:Small samples are usually sent by express (DHL, UPS, FEDEX, TNT). If the buyer has other opinions, both parties can discuss with each other.
Related Products
Recommend Products
Contact Us
Our address
Nan'an City, Quanzhou City Fujian PRC-China
Phone Number
+86 13215065797
sales5@forede.com
Hot Tags: automatic fire water monitor, China, manufacturers, suppliers, wholesale, price, Storage Sprinklers, Automatic Fire Water Cannon, Remote Control Water Cannon, Dry Type Sprinklers, FM 200, Explosion Remote Fire Monitor
Feature
- Hard anodized aluminum alloy construction
- Laser positioning indication, high-definition screen monitoring
- Straight stream & Fog or Straight Stream nozzle
- Electric control jetting Pattern: Straight stream,Fog
- Electric.driver and control unit box are waterproof
- Optional power supply 12V/24V DC(optional),or 100-230AC
- Explosion proof: Exd II BT4GB
