Products Description
Overview
forede® WFS2.AA080 Fire Water Monitor Geared Control with full 3" waterway provides flows of up to 4800 LPM (1270 GPM) and can be used with a choice of forede monitor zozzles to suit a wide range of specific applications. With full 360° rotation capabilities and adjustable elevation of 90° above and 60° below the horizontal, the PS10/80W-AH fixed station monitor is infinitely maneuverable via the wheels. Vertical and Horizontal quick-action locks allow the operator to fix the monitor swiftly to any position.
Available in a choice of either Lever-Operated or Geared models the PS10/80W-AH fixed station monitor is easily operated under pressure and maximizes performance through an efficient flow-engineered design. It is available with either 3" or 4" ANSI 150lb Flanged inlets for use on fixed pipework.
Features
Product Name: Fire Water Monitor Geared Control
Flow Rate: 4800 LPM
Jetting Pattern: Straight stream, Fog
Max. Reach: 85 meters
Products Parameters
forede® Fire Water Monitor Geared Control with different size and standard for option:
|
Model Number |
WFS2.AA080 | |||
|
Flow Rate |
4800 LPM Automatic Nozzle |
|||
|
Working Pressure |
8 Bar |
|||
|
Max. Reach |
85 meters @ 4800 LPM |
|||
|
Max. Fog Angle |
120° |
|||
|
Max Range Of Motion |
-45° to +75° Vertically, 340° Rotation, other degree available |
|||
|
Waterway Size |
3"(80mm) |
|||
|
Monitor Outlet |
2.5" (65mm) NH male thread |
|||
|
Monitor Inlet |
Flange 4" BS4504 is standard ( other sizes & standards are available ) |
|||
|
Material |
Monitor - SS304 stainless steel Nozzle & Hand wheel - Aluminium alloy |
|||
FAQ
Q: What is a Fire Water Monitor with Geared Control?
A fire water monitor with geared control is a manually operated firefighting device equipped with a gear transmission mechanism. This design allows operators to precisely control the monitor's horizontal (rotation) and vertical (elevation) movement with minimal effort.
Q: What are the advantages of geared control over direct manual operation?
Precise positioning of water or foam stream
Reduced operator effort, especially at high pressure
Smooth and stable movement
Better control in hazardous or long-duration firefighting scenarios
Q: Where are geared fire monitors commonly used?
They are widely used in:
Petrochemical plants
Oil & gas facilities
Tank farms
Warehouses
Marine and port terminals
Airports and industrial sites
Q: What is the typical flow range of these monitors?
Flow rates usually range from:
500 L/min to 5000+ L/min
(depending on model and application requirements)
Q: What materials are commonly used?
Common materials include:
Aluminum alloy (lightweight, corrosion-resistant)
Stainless steel (high corrosion resistance)
Carbon steel (heavy-duty industrial use)
