Products Description
- Aluminium alloy construction,hard anodized;
- Constant flow rate;
- Vertical travel of 180°,from -90° to +90°;
- 340° rotation horizontally;
- Electric control jetting Pattern: Straight stream,Fog;
- Electric.driver and control unit box are waterproof;
- Optional power supply 24V DC,or 100-230AC.
.
| Model |
PSKD10/80W-C |
PSKD12/100W-C |
| Flow Rate |
4800 LPM Constant Flow |
6000 LPM Constant Flow |
|
Working Pressure |
110 bar |
|
|
Max. Reach |
85 m |
90 m |
|
Max. Fog Angle |
120° |
|
|
Max Range Of Motion |
-90° to +90° Vertically, 340° Rotation,other degree available |
|
|
Power Supply |
DC 24V is standard |
|
|
Power Consumption |
≤200W |
|
|
Waterway Size |
4" (100mm) |
|
|
Monitor Outlet |
3.5" NH male thread |
|
|
Monitor Inlet |
Flange 4" ANSI 150# is standard,other size and standard available |
|
|
Material |
Monitor & Nozzle- Hard coated anodized aluminium alloy |
|
|
Control System |
ICS-01 or VMCS-01 |
|
Products Question
Q. Do your offer free sample for your clients?
A: Yes, we offer free sample for many of the products
Q. What's the MOQ of your products?
A: Our MOQ is one (1) piece/set.
Q. What's your payment terms?
A: We accept T/T, L/C, Western Union, Paypal,etc.
Q. How long is the delivery time?
A: Usually around 15 days after payment.
