Fire Water Monitor Control by electronic is made of SS304 stainless steel. LFire Water Monitor Control by electronic has the adjustable nozzle, the flow rate of Fire Water Monitor Control by electronic 1200-2400LPM, and the jetting range @8 Bar max. can reach 65 meters. The jetting pattern are straight stream fog.The Fire Water Monitor Control by electronic.
|
Model Number |
EFS1.BF020 |
EFS1.BF030 | EFS1.BF040 | EFS1.BS040 |
|
Flow Rate |
1200LPM |
1800LPM | 2400LPM | 1200-2400LPM |
|
Working Pressure |
8 Bar |
|||
|
Max. Reach @ 8 bar |
50 meters |
60 meters | 65 meters | 65 meters |
| Max.Fog Angle | 120° | |||
|
Max Range Of Motion |
-90° to +90° Vertically, 340° Rotation,other degree available |
|||
|
Turing Speed |
24°/Second rotation,24°/Second vertical |
|||
|
Power Supply |
DC 24 V is standard |
|||
|
Power Consumption |
≤200W |
|||
|
Waterway Size |
2.5"(65mm) |
|||
|
Monitor Outlet |
2.5" (65mm) NH |
|||
|
Monitor Inlet |
Flange 3''ANSI 150# is standard,other size and standard available |
|||
| Material |
Monitor-SS304 stainless steel is standard,SS316 is available Nozzle - Stainless Steel+Brass |
|||
FAQ:
Q:Do you have any MOQ limit?
A:For conventional products, Low MOQ, OEM products request 30-40days.
Q: Can we make field trips and visit your factory?
A: Yes, We are pleased you come to visit our factory. Welcome!
Q: What's your payment terms?
A :We accept T/T, L/C, Western Union, Paypal,etc.
Hot Tags: fire water monitor control by electronic, China, manufacturers, suppliers, wholesale, price, Pistol Grip Selectable Fire Nozzle, Fire Fighting Monitors, Fixed Water Cannon, Fire Hydrant With Wrench, Truck Fire Fighting Monitor, Wireless Fire Water Monitor
1) SS304 Stainless steel;
2) Nozzle - Stainless Steel+Brass;
3) Vertical travel of 180°,from -90°to +90°;
4) 360°rotation horizontally;
5) Electric control jetting Pattern: Straight stream,Fog;
6) Electric.driver and control unit box are waterproof;
7) Optional power supply 12V/24V DC(optional),or 100-230 V AC.
