Fire Water Monitor Control by electronic is made of SS304 stainless steel. LFire Water Monitor Control by electronic has the automatic nozzle, the flow rate of Fire Water Monitor Control by electronic 300-600/600-1200LPM, and the jetting range @8 Bar max. can reach 45 meters. The jetting pattern are straight stream fog.The Fire Water Monitor Control by electronic.
Model Number | PSKD8/10W-A | PSKD8/20W-A |
Flow Rate | 300-600LPM | 600-1200LPM |
Working Pressure | 8 Bar | 8 Bar |
Max. Reach @ 8 bar | 45 meters@600LPM | 45 meters@1200LPM |
| Max.Fog Angle | 120° | |
Max Range Of Motion | -90° to +90° Vertically, 340° Rotation,other degree available | |
Turing Speed | 24°/Second rotation,24°/Second vertical | |
Power Supply | DC 24 V is standard | |
Power Consumption | ≤200W | |
Waterway Size | 2"(50mm) | |
Monitor Outlet | 2" (50mm) NH | |
Monitor Inlet | Flange 2.5''ANSI 150# is standard,other size and standard available | |
| Material | Monitor-SS304 stainless steel is standard,SS316 is available Nozzle - Hard coated anodized aluminium alloy | |
Control System | ICS-01 or VMCS-01 | |
FAQ:
Q:Do you have any MOQ limit?
A:For conventional products, Low MOQ, OEM products request 30-40days.
Q: Can we make field trips and visit your factory?
A: Yes, We are pleased you come to visit our factory. Welcome!
Q: What's your payment terms?
A :We accept T/T, L/C, Western Union, Paypal,etc.
Hot Tags: fire water monitor control by electronic, China, manufacturers, suppliers, wholesale, price, Remote Fire Water Monitors, Wireless Remote Fire Water Monitor, Remote Control Fire Water Cannon, Wireless Fire Monitor, RC Fire Fighting Monitor, Pillar Fire Hydrant
1) SS304 Stainless steel;
2) Automatic monitor nozzle;
3) Vertical travel of 180°,from -90°to +90°;
4) 360°rotation horizontally;
5) Electric control jetting Pattern: Straight stream,Fog;
6) Electric.driver and control unit box are waterproof;
7) Optional power supply 12V/24V DC(optional),or 100-230 V AC.
