Products Description
This product is suitable for being equipped with light fire trucks and fire boats. It can also be used as the front monitor of firefighting vehicles to remove fire sources near the fire truck and effectively protect the safety of the fire truck. At the same time,the monitor can also be used as an industrial and mining enterprise and warehouse. Stationary fire extinguishing equipment in
Products Parameters
|
Model Number |
PSKD10/50W-A | PSKD10/60W-A | PSKD10/80W-A |
|---|---|---|---|
| Flow Rate |
3000 LPM Constant Flow
|
3600 LPM Constant Flow | 4800 LPM Constant Flow |
|
Working Pressure |
10 bar | ||
| Max. Reach | 75 meters | 75 meters | 85 meters |
| Max. Fog Angle | 120° | ||
| Max Range Of Motion |
-90° to +90° Vertically, 340° Rotation,other degree available
|
||
| Power Supply |
DC 24V is standard
|
||
| Power Consumption |
≤200W
|
||
| Waterway Size |
3"(80mm)
|
||
| Monitor Outlet | 2.5" (65mm) NH | ||
| Monitor Inlet |
Flange 4" ANSI 150# is standard,other size and standard available
|
||
| Material |
Monitor - SS304 stainless steel is standard,SS316 is available
Nozzle - Hard coated anodized aluminium alloy
|
||
| Control System |
ICS-01 or VMCS-01
|
||
monitor Description
faq
Lorem ipsum dolor sit amet consectetur adipisicing elit.
Q:1.How to have an order?
A:Before customers have an order, please tell us more details of the products you required which are good for us to introduce you or help you choose the best product.
Q:2.How long does it take to produce the product?
A:Conventional products and small quantities can be produced within 15 days. The specific production time needs to have specific products and product quantities to confirm.
Q:3.What can you buy from us?
A:Fire Sprinkler system,Foam system,Fire Monitor,Fire Nozzle,Fire Valves,Fire Hydrants
Q:4.How can we guarantee quality?
A:Always a pre-production sample before mass production;
Always final Inspection before shipment;
