Remote Control Fire Water Cannon

Remote Control Fire Water Cannon
Product Introduction:
XFS1.SF020 fire water cannon designed to meet the high level for safety and protection areas.With straight stream constant nozzle, can pinpoint the fire accurately, and put it out quickly.
Send Inquiry
Description
Technical Parameters

Remote Control Fire Water Cannon

Remote Control Fire Water Cannon -XFS1.SF020/030 flow rate can up to 1800LPM. It can meet both direct current and alternating current, and with less power consumption then make a good result for put fire out. Especially with explosion proof settings, it can work at a high risk area, and can work without personnal operations.


1) Aluminum alloy construction;

2) Constant nozzle, flow rate: 1200LPM/1800LPM;

3) With straight stream jetting pattern;

4) Explosion proof class: IICT4.



Material

Body

SS304 Stainless Steel

Nozzle

SS304 Stainless Steel

Model

XFS1.SF020

XFS1.SF030

Flow rate

1200LPM

1800LPM

Max.Jetting Range

53 m

60 m

Working pressure

0.8 MPa

Max.fog spray angle

120°

Rotation

360°

Elevate

-90° to +80°

Inlet

2.5"ANSI flange as standard, other size and standard also available

Outlet

2.5" NH male thread

Turning Speed

24°/second rotation, 106/second vertical

Power Supply

12V /24V DC is standard, 100-380V AC is also available

Power Consumption

24V@7.5


Main Product:

product-1600-443


FAQ

Q. Can I have a sample order?

A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.


Q: Are there any specifica installation requirements for Fire Monitor?

1) Height of the monitor is matching to the installation requirements;

2) The mounting arrangement is suitable to the back thrust from the monitor;

3) Ensure that the flange of the hydrant is matching to the monitor inlet flange;

4) Use approved gasket between flanges, and good quality nuts/ bolts;

5) Ensure that full rotation of the monitor is possible, and the height of the monitor handwheels is at proper height for operator use.


Order Information:

Dear Customer,
Before ordering, please contact with our sales team to discuss order information, such as Model Number, Flow Rate, Material, Control Ways, Package,Etc.
If you have any other requirements or wanna know more info about our products, welcome to contact as well. Our Sales team and Technical Department are willing to support you.




Hot Tags: remote control fire water cannon, China, manufacturers, suppliers, wholesale, price, Self Inducting Foam Monitor, Wireless Fire Water Monitor, Remote Explosion Proof Fire Monitor, Remote Fire Water Monitors, Electrical Fire Fighting Water Monitor, Fire Fighting Monitors
