Wireless Fire Water Monitor Fire Fighting
Forede PSKD EX-A Series fire water monitor have high flow rate, and can protect a large area. The flow rate up to 4800LPM,and max. can reach 80 meters.This products can be installed on firefighting car, offshore platform,and so on. This product is designed for high risk area, to meet the requirement for explosion-proof, and can scan the area automatically with a detector.
Technological Parameters
Material | Body | SS304 stainless steel; SS316 stainless steel | |
Nozzle | Hard coated anodized aluminum alloy | ||
Model | PLKD10/50WG-A | PLKD10/60WG-A | PLKD10/80WG-A |
Flow rate | 3000LPM | 3600LPM | 4800LPM |
Working Pressure | 10 Bar | 10 Bar | 10 Bar |
Max. Jetting Range | 70 m | 75 m | 85 m |
Max.fog spray angle | 120° | ||
Rotation | 360° | ||
Elevate | -60° to +90° | ||
Inlet | 4" ANSI 150# flange as standard, other size and standard also available | ||
Outlet | 2.5" NH male thread | ||
Power Supply | AC 220V | ||
Power Consumption | ≤200W | ||
Turning Speed | 7°/second rotaion,7°/second vertical move | ||
Detail Image
Main Product:
FAQ
Q:Where are Remote Control Monitor applications
A: RCMs find application in industries/ operations having severe fire hazards, such as Oil & Gas facilities, flammable liquid storage and processing, Ports, etc, where exposing personnel to the high radiant heat/ smoke and gases during fire incidents is not an option. RCMs provide the ideal solution to such problems as they can be operated from a safe and remote location.
Q:What are Remote Control Monitors?
A:Remote Control Monitors (RCM) are standard monitors fitted with arrangements to operate the same from a remote location. RCMs normally employ Electric or hydraulic motors to operate the swivel joints for vertical/ horizontal movement of the monitor, as well as to adjust the discharge pattern of the nozzle.
Q: What's the difference between remote control fire monitor and remote control water monitor?
A: Remote control monitor means fire fighting monitor is remote controlled. Remote control water monitor is one of remote control monitors, and this type fire fighting monitor can use via water. There's another type, remote control foam monitor, this product can use via foam concentrate.
Order Information:
Dear Customer,
Before ordering, please contact with our sales team to discuss order information, such as Model Number, Flow Rate, Material, Control Ways, Package,Etc.
If you have any other requirements or wanna know more info about our products, welcome to contact as well. Our Sales team and Technical Department are willing to support you.
Hot Tags: wireless fire water monitor fire fighting, China, manufacturers, suppliers, wholesale, price, Dry Fire Sprinklers, Remote Fire Water Monitors, Fixed Remote Control Foam Monitor, Extended Coverage Fire Sprinklers, Electric Fire Water Monitor, Fixed Remote Foam Monitor
1) SS304 stainless steel is standard, SS316 stainless steel is also available;
2) With automatic nozzle; flow rate up to 4800LPM;
3) Electric control jetting pattern: straight stream, fog;
4) Explosion proof class: IICT4.
