Products Description
Roof Fire Monitor come in a variety of sizes and styles, each with their own specifications and capabilities. However, they all serve the same crucial purpose – to deliver water or fire suppressant at a high pressure and from a safe distance.
One of the biggest advantages of a Roof Fire Monitor is its ability to deliver large amounts of water quickly. This can be critical in situations such as wildfires or large structure fires where time is of the essence. The high-pressure output from a fire monitor can also penetrate through walls and other obstacles, allowing firefighters to access areas that would otherwise be impossible to reach.
Another significant advantage of a Roof Fire Monitor is its ability to reduce the risk of injury or death for firefighters. By allowing them to fight fires from a distance, firefighters can avoid entering dangerous areas where they may become trapped or injured.
Overall, a Roof Fire Monitor is an essential tool for any firefighting team. It enables firefighters to respond to fires quickly and efficiently, while also minimizing the risk of injury or death. As technology continues to improve, we can expect to see even more advanced fire monitors in the future, further enhancing the ability of firefighters to keep us safe.

Technical Parameter
Model |
PSKD20A
|
PSKD30A
|
PSKD40A
|
PSKD20-40A
|
Flow Rate |
1200 LPM |
1800 LPM |
2400 LPM |
1200-1800-2400 LPM adjustable |
Working Pressure |
8 Bar |
8 Bar | 8 Bar | 8 Bar |
Max. Reach |
53 meters |
60 meters |
65 meters |
53-65 meters |
Max. Fog Angle |
120° |
|||
Max Range Of Motion |
-90° to +90° Vertically, 360° Rotation |
|||
turing Speed | 12°/second rotation, 8°/ second vertical | |||
Power supply | DC 24 V; AC 220 V | |||
Waterway Size |
2.5'' (65mm) |
|||
Monitor Outlet |
2.5'' nH male thread |
|||
Monitor Inlet |
Flange 4" BS4504 is standard ( other sizes & standards are available ) |
|||
Material |
Monitor - SS304 Nozzle - Hard coated anodized aluminium alloy |
FAQ
Contact US
Our address
NO.278-1, MEITING VILLAGE, MEILIN SUB-DISTRICT, NAN'AN CITY, QUANZHOU CITY, FUJIAN PROVINCE, CHINA.
Phone Number
0086-13107856309 (whatsApp)

About US
QUANZHOU FOREDE FIREFIGHTING EQUIPMENT CO.,LTD.
Since company was found in 2003, FOREDEFIRE has evolved and grown from a small factory in the yard with the limited capacity to only make sprinklers, to a sophisticated and leading company.
In 2013, FOREDEFIRE establish production base in Sanduo Industry Park, Jiangsu PRC to develop and improve fire monitor, fire nozzle, foam system device, fire robot etc. Increased production and enhanced quality and cost control to accommodate our continuing growth
large enterprise scale
Efficient and precise processing and testing equipment.
Standardized Production
Passed ISO9001, CE certification and obtained relevant patent certificates.
High-Quality Customized Services
No intermediate links, providing one-stop service from design, processing, mold trial to mass production.

Work Shop View - Fire Nozzle & Monitor








Hot Tags: roof fire monitor, China, manufacturers, suppliers, wholesale, price, Extended Coverage Fire Sprinklers, Wireless Fire Water Monitor Fire Fighting, Electrical Fire Fighting Water Monitor, RC Fire Fighting Monitor, Fire Hydrant With Wrench, Fixed Remote Control Foam Monitor
1) SS304 construction.
2) 1200-1800-2400 LPM flow rate (constant or adjustable flow).
3) Available for fog spray and straight jetting.
4) 360°rotation,-90°to + 90°Elevate
5) Easy to service and repair.
6) Wireless and manual control.
7) Light weight stable quality.
