Products Description
The device can be used in different fire scenarios, including buildings, factories, oil fields, airfields, wharves, and more. In large fires, the Water Foam Monitor can also work in conjunction with other firefighting equipment, such as water guns and fire extinguishers. In addition, the Water Foam Monitor has other advantages. For example, it can be controlled by a remote controller, simplifying the operation of firefighters, while also adapting to different spray distances and angles.
Products Parameters
|
Model Number |
PLKD8/24-B | PLKD8/32-B | PLKD8/40-B | |||
|---|---|---|---|---|---|---|
| Flow Rate | 1440 LPM | 1920 LPM | 2400 LPM | |||
|
Working Pressure |
8 Bar | 8 Bar | 8 Bar | |||
| Water Max. Reach | 55 meters | 60 meters | 65 meters | |||
| Foam Max. Reach | 42 meters | 48 meters | 55 meters | |||
| Max Range Of Motion |
-90° to +90° Vertically, 340° Rotation,other degree available
|
|||||
| Power Supply |
DC 24V is standard
|
|||||
| Waterway Size |
2.5"(65mm)
|
|||||
| Monitor Outlet |
2.5"NH
|
|||||
| Monitor Inlet |
Flange 2.5" ANSI 150# is standard,other size and standard available
|
|||||
| Material |
Monitor&Nozzle-Hard coated anodized aluminium alloy
|
|||||
| Control System |
ICS-01 or VMCS-01 |
|||||
Monitor Description
