Adjustable Flow Brass Monitor Nozzle

Adjustable Flow Brass Monitor Nozzle
Product Introduction:
The forede® Brand MBS040 Adjustable Flow Brass Monitor Nozzle is an essential tool for fire monitors, providing firefighters with the ability to control the flow of water to effectively combat fires. This nozzle is made of durable brass material, ensuring its reliability and longevity in high-pressure situations. With its adjustable flow feature, firefighters can easily regulate the water output to suit the specific needs of the fire they are facing. This flexibility allows for more efficient use of water resources, reducing waste and increasing the effectiveness of firefighting efforts. The MBS040 Brass Monitor Nozzle is easy to use and offers precise control, making it a valuable asset for any firefighting team. Its sturdy construction and dependable performance make it a dependable tool in the face of emergency situations. Overall, the MBS040 Adjustable Flow Brass Monitor Nozzle is a vital component of any firefighting arsenal, providing firefighters with the ability to effectively combat fires and protect lives and property. Its versatility and durability make it a must-have tool for any fire department.
Send Inquiry
Description
Technical Parameters

Descriptions

The forede® Brand MBS040 Adjustable Flow Brass Monitor Nozzle is an essential tool for fire monitors, providing firefighters with the ability to control the flow of water to effectively combat fires. This nozzle is made of durable brass material, ensuring its reliability and longevity in high-pressure situations.

With its adjustable flow feature, firefighters can easily regulate the water output to suit the specific needs of the fire they are facing. This flexibility allows for more efficient use of water resources, reducing waste and increasing the effectiveness of firefighting efforts.

The MBS040 Brass Monitor Nozzle is easy to use and offers precise control, making it a valuable asset for any firefighting team. Its sturdy construction and dependable performance make it a dependable tool in the face of emergency situations.

Overall, the MBS040 Adjustable Flow Brass Monitor Nozzle is a vital component of any firefighting arsenal, providing firefighters with the ability to effectively combat fires and protect lives and property. Its versatility and durability make it a must-have tool for any fire department.

01

Flow Rate Baffle Adjustment, Easy Flow Rate Adjust

The MBS040 nozzle comes with three standard flow rate, supporting flexible flow switching from 1200LPM/1800LPM/ 2400LPM by adjust the flow rate baffle, selectable flow with a fully machined waterway that ensures excellent stream quality.

02

Compact, Solid, Straight Steam With Far Reach And Fog

With bulid-in stream shapers, style MBS040 master stream nozzle forming a tight, solid straight water steam to have an far reach,with narrow and wide fog pattern, Pattern easily changed under flowing conditions from straight stream to 100° fog.

03

Havey Duty Brass Construction

The monitor nozzle core & shell,baffle,shapers,NH couplings are all made by brass material, control handle material is stainless steel 304, which is durable, pressure-resistant and anti-corrosion  for corrosive equipment applications.

-1-



Key Features

Durable heavy duty brass construction for corrosive equipment applications

Simple,rugged nozzle with superior stream quality and reach.

Powerful,steady, concentrated,solid stream and fog.

Customized to meet different flow rate @ different working pressure.

Extremly low maintenance, high quality components.

Adjust the flow rate by changing the flow rate baffle.

Suitable for most of fire monitor assembly of forede brand.

Build-in shape for incredible reach and stream quality.

Simply and qucikly twist the adjustment handle to select the straight and fog pattern.

3

Specifications

Style Number : MBS040

Monitor Nozzle Material: Brass

Pattern: Straight Steam,Narrow fog,Wide fog

Monitor Nozzle Type: Selectable gallonage master stream monitor nozzle.

 Max.Flow Rate: 2400 LPM

Media: Water

Control Type: Manual control by handle.

Inlet Size: 2.5 '' NH Female

Application: For fire monitor,for fire fighting.

Suitable Monitor Assembly: TFS1,TFS2.WFS1.WFS2

Surface Finishing: Sandblasted & acid-washing brass for corrssion ressistant.
Flow Rate (LPM): 1200-1800-2400 LPM Selectable Flow by spring loaded baffle (need to closed the valve).
Rated Working Pressure:

0.8Mpa/8 Bar/115psi.

Max Working Pressure: 1.38Mpa/13.8bar/200 psi.
Inlet Size: 2.5" NH Female (Other coupling style is acceptable).
Max.Reach:

50 meters @1200LPM,60 meters @1800LPM ,65 meters @2400lpm (@ 30 Degree,1.2 Meters To the Ground.Wind Speed <2m/s).

Max.Fog Angle: 100°.

Applications

222

Petrochemical

222

Fuel/Oil Storage Tank Area

22

Oil Rig

222

Airport & Hanger

2

Fire & Rescue Services

3

Fire Truck

66

Wildland Forest

9

Marine & Offshore

FAQ

1. What is the MBS040 adjustable flow brass monitor nozzle?

The MBS040 is fire nozzle constructed sandblasted & acid-washing brass for corrssion ressistant

It is supporting flexible flow switching from 1200LPM/1800LPM/ 2400LPM by spring loaded baffle.

2. How does an Adjustable Flow Brass Monitor Nozzle work?

It works by allowing the user to adjust the flow rate of the water by spring loaded baffle(Need to close valve) being discharged from the fire monitor, providing more control over the firefighting operation.

3. How to select the straight stream and fog pattern?

To select between a straight stream and a fog pattern on a fire monitor, simply twist the pattern adjustment handle (the outer sleeve on the nozzle).

4. Is the Adjustable Flow Brass Monitor Nozzle durable?

Yes, the Adjustable Flow Brass Monitor Nozzle core & shell,baffle,shapers,NH couplings are all made by brass material, control handle material is stainless steel 304.

5. How does the nozzle improve firefighting efficiency?

By offering precise control over water stream direction and flow rate, it helps firefighters target fires quickly and safely.

Important Information & Warming

⚠️

  • Designed for use with fire monitors – not suitable for handheld use
  • See Instruction before use.
  • Scheduled maintenance is necessary.
  • It's used for Class A/B Fire.
