Products Description
Master Stream Nozzle for Monitor
Forede Master Stream Nozzle is a critical component of fire monitoring systems, designed to deliver high-volume, high-pressure water or firefighting agents over long distances. Engineered for large-scale industrial, commercial, and municipal firefighting scenarios, this nozzle excels in suppressing high-intensity fires where rapid, targeted suppression is essential.
Master Stream Nozzles are built to handle extreme flow rates, typically ranging from 500 to 6,000 gallons per minute (GPM), depending on the model. Their robust construction-often using stainless steel, hard-anodized aluminum, or corrosion-resistant alloys-ensures durability in harsh environments.
Orifice Design: The nozzle's orifice size directly impacts flow rate and reach. Larger orifices enable higher volumes but require greater pressure (often 80–120 PSI) to maintain effective streams.
Stream Patterns: Most Master Stream Nozzles offer adjustable patterns, including:
Solid Stream: For long-distance penetration (up to 300 feet horizontally).
Fog/Spray: For vapor suppression and heat reduction in confined spaces.
Straight Bore: Maximizes water impact for structural firefighting.
Features:
Production Name: Fire water cannon nozzle
Flow Rate: 20-30-40 LPS Selectable
Jetting Pattern: Straight Stream, Fog
Max. Reach: 65 meters
Technical Parameter
|
Model Number |
FRD-SMN | |||
| Flow Rate | 20-30-40 LPS Selectable Flow | |||
| Working Pressure | 8 Bar | |||
| Max. Reach | 65 meters @ 2400 LPM | |||
| Max. Fog Angle | 120° | |||
| Material | Stainless Steel+Brass | |||
| Monitor Inlet | 2.5" NH Female | |||
| Flow Pattern | Selectable | |||
FAQ
Q: What is the typical flow rate range of a Master Stream Nozzle for Monitor?
A: The flow rate ranges from 150 GPM (600 LPM) to 1,250GPM (4,800 LPM), depending on the model.
Q: What operating pressures do Master Stream Nozzles support?
A: Pressures range from 7 bar (100 PSI) to 12 bar (174 PSI), with some models maintaining consistent performance at fixed pressures.
Q: What stream patterns are available?
A: Adjustable patterns include solid stream (for long-distance reach), fog/spray (for heat reduction), and straight bore (for structural firefighting).
Q:What is the standard inlet size for Master Stream Nozzles?
A：Common inlet sizes include 2.5-inch (64 mm) NH female threads for compatibility with monitors and hoses.
