Product Introduction:

L1S475 is selectable flow fire nozzle, the flow rate is 115-230-360-475 LPM; The multi-function fire water gun is also called recoilless water gun. The reason why it is designed like this is mainly to reduce the recoil force, which can play a better fire fighting effect, and at the same time prevent the recoil from injuring firefighters when spraying. Common multi-function fire water guns include adjustable flow type water guns, automatic flow adjustment type water guns, constant flow type water guns, constant pressure type water guns, high pressure water guns, etc.

Send Inquiry

Description

Technical Parameters

The fire water nozzle has a small recoil, which can significantly improve the safety of the water nozzle. Especially in environments with poor stability such as roofs, slopes, and lift trucks, recoil becomes a very dangerous factor. After using the water nozzle, this kind of danger can be avoided.

Specification:

* the flow rate of L1S475 is a range from 115-230-360-475 LPM;

* Jetting pattern: Straight stream,Narrow fog,Wide fog,

* 1/4 turn from straight stream to wide fog

* the coupling standard of this fire hose nozzle has INST; NH;GOST;STORZ;etc;

* the max. fog angle can reach 120°, and the max. jetting range can reach 40 meters;

* while, 2.5 inch fire hose nozzle is made of hard anodized aluminium alloy, is lightweight;

* a pistol grip which is convenient for firefighters.

Moedel	Material	Inlet Size	Working Pressure	Max.Fog Angle	Max.Reach
L1S475-40	Hard Anodized Aluminium Alloy	1.5''(40mm)	7 bar	120°	40m @7 bar
L1S475-50	Hard Anodized Aluminium Alloy	2''(50mm)	7 bar	120°	40m@7 bar
L1S475-65	Hard Anodized Aluminium Alloy	2.5''(65mm)	7 bar	120°	40m@7 bar

Dimension:

shiyi

1)Valve Handle is to open or close the flow;

2) SS-FOG Adjust also called pattern adjustor, this part is to change the jetting pattern between fog and straight stream;

3) Pistol Grip which is a part convenient for firefighters carrying on;

4) Flow rate adjust can change the flow rate: 115-230-360-475 LPM;

5) Coupling is 360°rotation.

FAQ:

Q:How to mail the samples?

A:Small samples are usually sent by express (DHL, UPS, FEDEX, TNT). If the buyer has other opinions, both parties can discuss with each other.

Q:How to have an order?

A:Before customers have an order, please tell us more details of the products you required which are good for us to introduce you or help you choose the best product.

Q:Do you have any MOQ limit?

A:For conventional products, Low MOQ, OEM products request 30-40days.

Hot Tags: 475lpm selectable flow fire nozzle, China, manufacturers, suppliers, wholesale, price, 3 Inch Fire Hose Nozzle, Nozzle Type Fire Sprinkler, Automatic Fire Hose Nozzle, American Pistol Grip Fire Nozzle, Pistol Grip Gun Nozzle, All Purpose Fire Nozzle

Flow Rate: 115-230-360-475LPM(selectable flow);
Jetting Pattern: Straight stream,Narrow fog,Wide fog ;
1/4 turn from straight stream to wide fog ;
360° Swivel inlet, full time, even after tightening ;
Compatible with Quick Attach Foam Tube ;
Coupling standard: Storz,NH,INST,GOST,Machino,etc.
