forede® Selectable Gallonage Fire Nozzle Introduction

The forede® Selectable Gallonage Fire Nozzle also known as selectable hose nozzle, fire water nozzle, which is a high-quality fire nozzle with an adjustable flow range and a choice of different inlet sizes and connections. It is made of hard-anodized aluminum and is able to withstand harsh climate and environmental conditions. This makes it a reliable and long-lasting tool suitable for a variety of different firefighting jobs.



forede® Selectable Gallonage Fire Hose Nozzle is a new generation of fire nozzle that offers firefighters a wide range of flow rates and patterns to adapt to various fire situations. The Forede® fire pistol grip nozzle has a unique feature of a selectable gallonage ring, which allows the user to choose the desired flow rate by simply turning the ring. The Forede® fire aluminum nozzle is easy to use, lightweight, durable, and compatible with most fire hoses and couplings.





types of selectable Gallonage Fire Fighting Nozzle

What We have?

forede® offers selectable fire nozzles in various flow rates, including 60LPM, 150LPM, 235LPM, 475LPM, and 950LPM. This wide range of flow rates allows firefighters to adjust the water pressure and flow to suit the requirements of the situation.

60LPM Selectable Gallonage Nozzle

150LPM Selectable Gallonage Nozzle

235LPM Selectable Gallonage Nozzle

475LPM Selectable Gallonage Nozzle

950LPM Selectable Gallonage Nozzle



 15-30-45-60LPM Selectable Gallonage Hose Nozzle.

The QLD6.0/1.0III  series Selectable gallonage fire hose nozzle with an adjustable flow range of 15-30-45-60LPM, which is ideal for small-scale firefighting,such as forest fire fighting.It is easy to be handheld and operated with pistol grip by fire fighters .Firefighter can use Narrow and wide fog pattern to prevent fire from burning themself,and breaks its stream into small droplets. By doing so, its stream achieves a greater surface area, and thus a greater rate of heat absorption.Fire fighter also can use straight steam to produce a highly concentrated stream of water, making them ideal for penetrating thick layers of fire-retardant materials, such as foam or insulation. They come in sizes ranging from 1 inch to 2.5 inches, with a maximum reach of up to 35 meters.It is avaliable with Storz,NH,Machino,Gost,BS336 Instatanenous Coupling.

Fire Nozzle Types Flow Rate Jetting Pattern Work.Pressure Material Inlet Size
Adjustable Flow 15-30-45-60LPM Straight Stream, Narrow Fog, Wide Fog 6 Bar, Low Pressure Aluminum Alloy 3/4 Inch,1 Inch

 19-38-95-150LPM Selectable Gallonage Fire fighting Nozzle.

The QLD6.0/2.5III series Selectable gallonage fire low pressure nozzle with an adjustable flow range of 19-38-95-150LPM, which is ideal for small-scale firefighting,such as forest fire fighting.It is easy to be handheld and operated with pistol grip by fire fighters .Firefighter can use Narrow and wide fog pattern to prevent fire from burning themself,and breaks its stream into small droplets. By doing so, its stream achieves a greater surface area, and thus a greater rate of heat absorption.Fire fighter also can use straight steam to produce a highly concentrated stream of water, making them ideal for penetrating thick layers of fire-retardant materials, such as foam or insulation. They come in sizes ranging from 1 inch to 2.5 inches, with a maximum reach of up to 36 meters.It is avaliable with Storz,NH,Machino,Gost,BS336 Instatanenous Coupling.

Fire Nozzle Types Flow Rate Jetting Pattern Work.Pressure Material Inlet Size
Adjustable Flow 19-38-95-150LPM Straight Stream, Narrow Fog, Wide Fog 6 Bar, Low Pressure Aluminum Alloy 1 Inch, 1.5 Inch

 60-130-235LPM Adjustable Flow Fire Hose Nozzle.

The QLD6.0/4III series Selectable gallonage fire water hose nozzle with an adjustable flow range of 60-130-235LPM, which is ideal for small-scale firefighting,such as forest fire fighting.It is easy to be handheld and operated with pistol grip by fire fighters .Firefighter can use Narrow and wide fog pattern to prevent fire from burning themself,and breaks its stream into small droplets. By doing so, its stream achieves a greater surface area, and thus a greater rate of heat absorption.Fire fighter also can use straight steam to produce a highly concentrated stream of water, making them ideal for penetrating thick layers of fire-retardant materials, such as foam or insulation. They come in sizes ranging from 1 inch to 2.5 inches, with a maximum reach of up to 37 meters.It is avaliable with Storz,NH,Machino,Gost,BS336 Instatanenous Coupling.

Fire Nozzle Types Flow Rate Jetting Pattern Work.Pressure Material Inlet Size
Adjustable Flow 60-130-235LPM Straight Stream, Narrow Fog, Wide Fog 6 Bar, Low Pressure Aluminum Alloy 1 Inch, 1.5 Inch

 115-230-360-475LPM Adjustable Fire Water Nozzle.

The QLD6.0/8III series Selectable gallonage fire fighting hose nozzle with an adjustable flow range of 115-230-360-475LPM, which is ideal for small-scale firefighting,such as forest fire fighting.It is easy to be handheld and operated with pistol grip by fire fighters .Firefighter can use Narrow and wide fog pattern to prevent fire from burning themself,and breaks its stream into small droplets. By doing so, its stream achieves a greater surface area, and thus a greater rate of heat absorption.Fire fighter also can use straight steam to produce a highly concentrated stream of water, making them ideal for penetrating thick layers of fire-retardant materials, such as foam or insulation. They come in sizes ranging from 1.5 inch to 2.5 inches, with a maximum reach of up to 42 meters.It is avaliable with Storz,NH,Machino,Gost,BS336 Instatanenous Coupling.

Fire Nozzle Types Flow Rate Jetting Pattern Work.Pressure Material Inlet Size
Adjustable Flow 115-230-360-475LPM Straight Stream, Narrow Fog, Wide Fog 7 Bar, Low Pressure Aluminum Alloy 1.5 Inch, 2 Inch, 2.5 Inch

360-475-560-760-950LPM Selectable Gallonage Water Nozzle.

The QLD7.0/15III series Selectable gallonage fire water nozzle with an adjustable flow range of 360-475-560-760-950LPM, which is ideal for small-scale firefighting,such as forest fire fighting.It is easy to be handheld and operated with pistol grip by fire fighters .Firefighter can use Narrow and wide fog pattern to prevent fire from burning themself,and breaks its stream into small droplets. By doing so, its stream achieves a greater surface area, and thus a greater rate of heat absorption.Fire fighter also can use straight steam to produce a highly concentrated stream of water, making them ideal for penetrating thick layers of fire-retardant materials, such as foam or insulation. They come in sizes ranging from 1 inch to 2.5 inches, with a maximum reach of up to 55 meters.It is avaliable with Storz,NH,Machino,Gost,BS336 Instatanenous Coupling.

Fire Nozzle Types Flow Rate Jetting Pattern Work.Pressure Material Inlet Size
Adjustable Flow 360-475-560-760-950LPM Straight Stream, Narrow Fog, Wide Fog 7 Bar, Low Pressure Aluminum Alloy 2.5 inch
Advantages of  forede® Selectable Fire Nozzle

Selectable Flow Rate

With the forede® Selectable Fire Nozzle, you can easily adjust the water flow from Min.15LPM to Max.950LPM to suit the needs of any situation. Whether you need a high-pressure jet stream or a gentle spray for spreading water over a large area, this nozzle has got you covered. This versatility makes the forede® Selectable Fire Nozzle an indispensable tool for firefighting.

Lightweight & Durable Construction

Unlike other fire hoses that can be heavy and cumbersome, the forede® Selectable Fire Nozzle is lightweight and easy to handle. This is especially important when you consider the physical demands of firefighting. With this nozzle, firefighters can move more easily and quickly, without being slowed down by heavy equipment.

Impressive Reach

One of the standout features of the forede® Selectable Fire Nozzle is its impressive reach. It can reach a minimum distance of 35 meters at 6 bar and a maximum distance of 55 meters at 7 bar. This makes it an ideal choice for tackling fires in both open spaces and hard-to-reach areas, it is a reliable and effective choice for battling fires of all sizes.



Superior Surface Treatment

To further enhance the durability of forede® Selectable Fire Nozzle, we have also incorporated a superior surface treatment. The Hard Anodized surface treatment provides a strong protective layer that helps to prevent corrosion, scratches, and other forms of damage. This surface treatment not only adds an extra layer of protection but also provides an attractive, uniform finish that is easy to clean and maintain.





  • 475LPM Fire Nozzles Gun
    Available in three different models with varying inlet sizes, the Selectable Fire Nozzle works at a maximum pressure of 7 bar and has a maximum reach of 42 meters. Its fog angle can be adjusted up...
    read more
  • 500LPM Fire Nozzle Selectable QLD6.0/8III
    Fire Nozzle Selectable for Firefighting has many advantages,it can flexibly respond to different fires. This is very important for rescue efforts, because firefighters need to adjust the amount of...
    read more
  • 25mm Metal Adjustable Nozzle Fire Fighting
    QLD6.0/4III 25mm metal adjustable nozzle fire fighting is made of hard anodized aluminium alloy, it can reach 115-230-360-475 flow rate when connected with the hose, the jetting pattern can change...
    read more
  • Jet Fire Hose Nozzle
    QLD6.0/4III jet fire hose nozzle is made of hard anodized aluminium alloy, it can reach 115-230-360-475 flow rate when connected with the hose, the jetting pattern can change between straight...
    read more
  • Fire Hose Gun Nozzle
    QLD6.0/2.5III fire hose gun nozzle is made of hard anodized aluminium alloy, it can reach 115-230-360-475 flow rate when connected with the hose, the jetting pattern can change between straight...
    read more
  • 4-position Fire Hose Nozzle
    QLD6.0/2.5III 4-position fire hose nozzle is made of hard anodized aluminium alloy, it can reach 115-230-360-475 flow rate when connected with the hose, the jetting pattern can change between...
    read more
  • Fire Fighter Nozzle
    QLD6.0/2.5III Fire fighter nozzle is made of hard anodized aluminium alloy, it can reach 115-230-360-475 flow rate when connected with the hose, the jetting pattern can change between straight...
    read more
  • Fire Truck Water Nozzle
    QLD6.0/2.5III fire truck water nozzle is made of hard anodized aluminium alloy, it can reach 115-230-360-475 flow rate when connected with the hose, the jetting pattern can change between straight...
    read more
  • 1 Inch Fire Nozzle
    QLD6.0/2.5III 1 inch fire nozzle is made of hard anodized aluminium alloy, it can reach 115-230-360-475 flow rate when connected with the hose, the jetting pattern can change between straight...
    read more
  • Handheld Hose Nozzle
    forede® L1S475 handheld hose nozzle is a firefighting nozzle designed for ease of handling, control, and operator comfort. It is commonly used with fire hoses in municipal, industrial, and...
    read more
  • Hand Held Nozzle Pistol Grip Type
    forede® L1S475 hand held nozzle pistol grip type is a firefighting nozzle designed for ease of handling, control, and operator comfort. It is commonly used with fire hoses in municipal,...
    read more
  • Hand Held Fire Nozzle
    forede® L1S475 hand held fire nozzle is a type of fire hose nozzle (or spray nozzle) designed to be operated manually by a firefighter or operator, rather than being mounted or fixed. It allows...
    read more
First 1234567 Last

Selectable Fire Nozzle Applications
1
01

Irrigation Plant

Fire Selectable Nozzle of Irrigation Plant Applications is a revolutionary technology that has brought a positive change to the irrigation industry. It is an advanced system that allows farmers to easily control the flow of water in their irrigation systems. This nozzle is highly efficient and effective in water management, which makes it an ideal choice for large-scale agricultural operations.



The Fire Selectable Nozzle is a versatile tool that can be used in a wide range of irrigation systems such as sprinkler, center pivot, and drip irrigation systems. It is easy to install and operate, making it an excellent choice for those who want to automate their irrigation systems. With this technology, farmers can save water and reduce their overall water usage, which helps to conserve this precious resource.



Furthermore, this innovative technology is environmentally friendly and contributes to sustainable agriculture practices. It reduces the amount of water that is lost through evaporation and runoff, which can harm the environment. It also helps to reduce the amount of energy required to irrigate crops, which ultimately helps to reduce the carbon footprint of agriculture.

02

controlling and containing wildfires

One of the key advantages of the Fire Selectable Nozzle is its versatility. These nozzles can be adjusted to produce different spray patterns, allowing firefighters to customize their approach based on the specific needs of the situation. This flexibility allows them to adapt quickly to changing conditions and effectively manage the fire.



Another benefit of the Fire Selectable Nozzle is its effectiveness in conserving water. By using a more focused spray pattern, less water is needed to achieve the same level of fire control. This means that firefighters can work longer and more efficiently without having to constantly refill their water supply.



The Fire Selectable Nozzle is also easier to use and maintain than traditional firefighting equipment. With its simple design and intuitive controls, firefighters can quickly master the tool and put it to use in the field. The lack of complex moving parts also means that maintenance requirements are minimal, reducing downtime and saving resources

f01d5f6d0d34c2ab8a7937f6b06e35bb
maxresdefault
03

Fire Training

The development of the selectable fire nozzle has revolutionized the firefighting industry and has been instrumental in the fire department's efforts to extinguish fires quickly and efficiently. This innovative device allows firefighters to adjust the water flow rate and pattern, enabling them to direct the water stream precisely where they need it. This level of control is critical in extinguishing fires effectively while preventing unnecessary water damage to the surrounding areas. The selectable fire nozzle has become an essential tool in the firefighter's arsenal, making their jobs easier and more efficient.



Furthermore, fire training applications have also seen significant improvements in recent years. Modern fire training programs incorporate the latest technologies to provide firefighters with realistic training scenarios to prepare them for real-world situations. The use of virtual reality simulations, fire extinguisher training, and live fire training exercises has become common practice in the firefighting industry. These advancements in fire training are essential in ensuring the safety of firefighters during emergency situations.

04

Forest Fires

A selectable fire nozzle is a specialized nozzle that allows firefighters to adjust the water flow and pattern to suit the specific needs of the fire. This flexibility is particularly important when fighting forest fires, which can vary greatly in terms of intensity, location, and fuel type. By being able to adjust the nozzle accordingly, firefighters can better control the spread of the fire and prevent further damage.



In addition to providing flexibility, the selectable fire nozzle is also designed to be highly efficient. It is capable of delivering large amounts of water over a wide area, which is crucial for putting out large fires. Moreover, the nozzle is designed to minimize wastage of water and ensure that the water is directed precisely where it is needed. This helps to conserve resources and prevent undue damage to the environment.



Another benefit of the selectable fire nozzle for forest fire applications is its durability and reliability. These nozzles are built to withstand harsh conditions, such as extreme heat, cold, and moisture. They are also designed to be easy to use and maintain, allowing firefighters to focus on their primary goal of containing and extinguishing the fire.

pexels-milton-moreira-937615011


We're well-known as one of the leading selectable fire nozzle manufacturers and suppliers in China for our quality products and good service. Please feel free to wholesale selectable fire nozzle at competitive price from our factory. Contact us for more details.
