Fire Fighting Nozzle has a long spray distance, and the DC range can reach 36-40 meters;
Fire Fighting Nozzle has a highly refined spray, and the external movable atomizing gear ring rotates at a high speed under water pressure to force the atomizing particles to be refined, so it can also be used as a smoke suppressor, and the spray angle is 120°.
The nozzle is equipped with flushing adjustment gear to prevent sandstone and garbage from blocking.
Material | Body | Hard Anodized Aluminum Alloy |
Ball Valve | ABS(standard), Aluminum Alloy/stainless steel (optional) | |
Valve Handle | ABS(standard), Aluminum Alloy(optional) | |
Pistol Grip | ABS | |
Bumper | Rubber | |
Working pressure | 7 bar | |
Jetting Range | 40 meters @ 7 bar | |
Max. Fog angle | 120° | |
Flow Range | 115 - 230 - 360 - 475 LPM - Flush, Five pattern adjustable | |
Inlet | 2.5 inch, available for Storz,NH,INST,Machino.etc. | |
Hot Tags: fire fighting nozzle, China, manufacturers, suppliers, wholesale, price, Nozzle Type Fire Sprinkler, Forestry Fire Nozzle, American Pistol Grip Fire Nozzle, Fire Turbo Nozzle, Handline Fire Nozzle, Fire Fighting Hydrant System
1)Pattern identification .
2) Hard anodized aluminum , Laser engraved .
3) Simple to operate (1/4 turn from straight stream to fog) .
4) Raised lug marks straight stream for limited visibility operations .
5) Easy to service & repair .
6) Compatible with quick attach foam tube .
7) Swivel inlet .
8) Low maintenance .
9) Light weight .
10) OEM Servise
