Name: Ceiling Fire Sprinkler
Brand: FOREDE
SKU: 217795454

Description

Technical Parameters

Concealed Fire Sprinkler

Ceiling fire sprinklers are an important safety feature that plays a crucial role in protecting buildings and their occupants from the potentially devastating effects of fire. These sprinklers are designed to quickly detect and extinguish fires that start in the ceiling or upper walls of a building.

One of the main benefits of ceiling fire sprinklers is their ability to control fires before they can become large and unmanageable. This can help minimize damage to the building and its contents, as well as reduce the risk of injury or death to occupants.

Another advantage of ceiling fire sprinklers is their versatility. They can be installed in a wide variety of buildings, including residential homes, office buildings, hospitals, and schools. They are also available in different sizes and designs, making it easy to find a sprinkler system that meets the specific needs of each building.

Furthermore, ceiling fire sprinklers can be highly effective at preventing the spread of fire. By quickly extinguishing the flames, they help prevent the fire from spreading to other parts of the building or neighboring structures.

Specification

Model Number	Connection	K Factor	Temperature	Response	Glass Bulb	RTI(m·s)0.5
K-ZSTDQ 80-57°C Q3	3/4" (DN20) BSP	K5.6@US (80@Metric)	57°C	Quick	Ø5mm, Orange	≤50
K-ZSTDQ 80-68°C Q3	3/4" (DN20) BSP	K5.6@US (80@Metric)	68°C	Quick	Ø5mm, Red	≤50
K-ZSTDQ 80-79°C Q3	3/4" (DN20) BSP	K5.6@US (80@Metric)	79°C	Quick	Ø5mm, Yellow	≤50
K-ZSTDQ 80-93°C Q3	3/4" (DN20) BSP	K5.6@US (80@Metric)	93°C	Quick	Ø5mm, Green	≤50
K-ZSTDQ 80-141°C Q3	3/4" (DN20) BSP	K5.6@US (80@Metric)	141°C	Quick	Ø5mm, Blue	≤50
