K=5.6/8.0 FIRE SPRINKLER
The Forede Side wall type sprinkling by the wall installation, suitable for the installation of more difficult places, mainly used for the office, door hall, lounge, corridor, guest rooms and other light dangerous parts of the building. The roof is a horizontal light danger grade, medium danger grade I grade bedroom and office, can use side wall type nozzle.
Features:
- K FACTOR：K 5.6 @ US(80@Metric)
- Thread Size：DN15(1/2'')
- Connecting Thread: BSP (NPT Optional)
- Main Material: Brass
- Sensitive Element: YF® Brand Glass Bulb (JOB® Glass Bulb Optional);
- Seal Material: NBR(Teflon Optional)
- Surface Finishing : Chrome (Natural Brass Optional).
| Model Number | Size | K factor | Tempurature | Response Type | Glass Bulb |
| FRD003-57℃ | 1/2''(DN15) | 5.6 | 57℃ | Standard | 5mm,Orange |
| FRD003-68℃ | 1/2''(DN15) | 5.6 | 68℃ | Standard | 5mm,Red |
| FRD003-79℃ | 1/2''(DN15) | 5.6 | 79℃ | Standard | 5mm,Yellow |
| FRD003-93℃ | 1/2''(DN15) | 5.6 | 93℃ | Standard | 5mm,Green |
| FRD003-141℃ | 1/2''(DN15) | 5.6 | 141℃ | Standard | 5mm,Blue |
| K-FRD003-57℃ | 1/2''(DN15) | 5.6 | 57℃ | Quick | 3mm,Orange |
| K-FRD003-68℃ | 1/2''(DN15) | 5.6 | 68℃ | Quick | 3mm,Red |
| K-FRD003-79℃ | 1/2''(DN15) | 5.6 | 79℃ | Quick | 3mm,Yellow |
| K-FRD003-93℃ | 1/2''(DN15) | 5.6 | 93℃ | Quick | 3mm,Green |
| K-FRD003-141℃ | 1/2''(DN15) | 5.6 | 141℃ | Quick | 3mm,Blue |
Oeder Information:
Dear Customer,
If you have any other requirements or wanna know more info about our products, welcome to contact as well. Our Sales team and Technical Department are willing to support you.
FAQ:
Q1. Can I have a sample order?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A:Sample needs 7-15 days, mass production time needs 30-40 weeks for order quantity more than 1 container.
Q3. Do you have any MOQ limit?
A: For conventional products, Low MOQ, OEM products request 30-40days.
