K=5.6/8.0 UPRIGHT STANDARD FIRE SPRINKLER
The upright standard fire sprinkler is installed upright on the water supply branch pipe. The shape of the sprinkler is a parabolic shape. It sprays 80 to 100% of the total water volume downward, and part of it is sprayed to the ceiling. It is suitable for installation in places with many moving objects and prone to collision, such as In the warehouse, it can also be concealed on the roof in the interlayer of the ceiling of the room to protect the ceiling boron with more flammable substances. (For places without suspended ceilings, when the water distribution branch pipes are arranged under the beams, the vertical type should be used. The parts that are prone to collision should use protective cover sprinklers or ceiling type sprinklers)
Features:
- K FACTOR：K 5.6 @ US(80@Metric)
- Thread Size：DN15(1/2'')
- Connecting Thread: BSP (NPT Optional)
- Main Material: Brass
- Sensitive Element: YF® Brand Glass Bulb (JOB® Glass Bulb Optional);
- Seal Material: NBR(Teflon Optional)
- Surface Finishing : Chrome (Natural Brass Optional).
| Model Number | Size | K factor | Tempurature | Response Type | Glass Bulb |
| FRD001-57℃ | 1/2''(DN15) | 5.6 | 57℃ | Standard | 5mm,Orange |
| FRD001-68℃ | 1/2''(DN15) | 5.6 | 68℃ | Standard | 5mm,Red |
| FRD001-79℃ | 1/2''(DN15) | 5.6 | 79℃ | Standard | 5mm,Yellow |
| FRD001-93℃ | 1/2''(DN15) | 5.6 | 93℃ | Standard | 5mm,Green |
| FRD001-141℃ | 1/2''(DN15) | 5.6 | 141℃ | Standard | 5mm,Blue |
| K-FRD001-57℃ | 1/2''(DN15) | 5.6 | 57℃ | Quick | 3mm,Orange |
| K-FRD001-68℃ | 1/2''(DN15) | 5.6 | 68℃ | Quick | 3mm,Red |
| K-FRD001-79℃ | 1/2''(DN15) | 5.6 | 79℃ | Quick | 3mm,Yellow |
| K-FRD001-93℃ | 1/2''(DN15) | 5.6 | 93℃ | Quick | 3mm,Green |
| K-FRD001-141℃ | 1/2''(DN15) | 5.6 | 141℃ | Quick | 3mm,Blue |
Oeder Information:
Dear Customer,
If you have any other requirements or wanna know more info about our products, welcome to contact as well. Our Sales team and Technical Department are willing to support you.
FAQ:
Q. Can I have a sample order?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q. What about the lead time?
A:Sample needs 7-15 days, mass production time needs 30-40 weeks for order quantity more than 1 container.
Q. Do you have any MOQ limit?
A: For conventional products, Low MOQ, OEM products request 30-40days.
Q.Where is your company?
A:NO. 1,Building 29#,B Zone,Chenghui International Trading Market,Xiamei Town,Nan'an City,Fujian Province,China.
Q. Do you have warranty?
A:yes, all products have one year warranty.
