Name: China Foam Chamber For Tanks Manufacturers, Suppliers - Wholesale Price - FOREDE
Brand: Forede
SKU: 257276686

Description

Technical Parameters

↵

Products Description

forede ® Foam Chamber For Tanks

forede® Foam Chamber for Tanks Inlet sizes range from DN65 to DN150, while outlet sizes available are 4'', 6'', 8'' and 10''. Media of forede® Foam Chamber for Tanks used is foam, which is an effective and reliable substance for firefighting and rescue operations. This forede® Foam Chamber for Tanks is mainly intended for use in fire tanks, but can be used for various other applications too.

The Forede® Foam Chamber for Tanks is a must-have for anyone involved in the fight against fire. forede® Foam Chamber for Tanks is a durable and efficient tool that helps save lives and property. The forede® Foam Chamber for Tanks is designed and manufactured to meet international standards of quality and safety.

Products Feature

Body Material: Carbon Steel ;

Expansion: Low Expansion ;

Working Pressure: 6 Bar ;

Flow Rate : 4/8/16/24/32/48/56/68LPS ;

Inlet Size: DN65/DN80/DN100/DN150

Outlet Size: 4'' / 6'' / 8'' / 10''.

Media : Foam ;

Application: For fire resuce,for fire fighting,for fire tank ;

Technical Parameter

forede ® Foam Chamber For Tanks

Our Foam Chamber for Tanks is a result of our commitment to quality and innovation.

Number	Inlet Size	Outlet Size	Flow Rate	Installation
PCL-F1	2.5''(DN65)	4''(DN100)	240LPM	Vertical
			480LPM
PCL-F2	3''(DN80)	6''(DN150)	960LPM	Vertical
			1440LPM
PCL-F3	4''(DN100)	8''(DN200)	1920LPM	Vertical
			2880LPM
PCL-F4	6''(DN150)	10''(DN250)	3360LPM	Vertical
			4080LPM

Frequently Ased Questiones

What is a foam chamber, and how does it work?

A foam chamber is a type of fire suppression device that injects foam into a storage tank to prevent or extinguish a fire. It works by discharging foam through the inlet orifice and dispersing it evenly across the surface of the liquid. As the foam spreads, it creates a vapor seal that suppresses the flames and prevents oxygen from reaching the fuel source.

What is the flow rate of a foam chamber?

The flow rate of a foam chamber varies depending on the size and model. For example, the PCL-F1 foam chamber has a flow rate of 240 liters per minute (LPM), while the PCL-F4 has a flow rate of 1920 LPM. It is essential to select a foam chamber that has a flow rate compatible with the size and type of storage tank.

What is the installation process for a foam chamber?

The installation process for a foam chamber involves several steps. First, the foam chamber should be properly sized based on the tank's size and characteristics. The foam chamber should be mounted near the top of the tank, vertically, on the inlet pipe. Next, the foam concentrate should be mixed and added to the tank. The system should be tested to ensure that the foam chamber is working correctly, and the foam is being discharged appropriately.

What is the inlet and outlet size of a foam chamber?

The inlet and outlet size of a foam chamber varies depending on the model. For example, the PCL-F1 has a 1/2 inch (DN65) inlet size and a 4 inch (DN100) outlet size, while the PCL-F4 has an 6 inch (DN150) outlet size and a 10 inch (DN250) inlet size. It is essential to select a foam chamber with the appropriate inlet and outlet size based on the storage tank's specifications.

What is the maximum flow rate of PCL-F4 foam chamber for tanks?

The maximum flow rate of PCL-F4 foam chamber for tanks is 4080 LPM.
