Air Foam Chamber
The foam chamber is fixedly installed on the top wall of the oil tank. When the foam liquid with a certain mixing ratio passes through foam chamber, it sucks a large amount of air to generate foam, and sprays the foam into the combustion liquid surface to form a foam layer or a film, which is a low multiple. Key equipment on spray foam fire extinguishing system.
Feature:
Expansion :Low expansion,≥ 5 Times;
Flange End: ANSI / BS4504 / GB/;
Main Material: Carbon Steel;
Installation Type: Vertical Installation;
Working Pressure Range: 0.3-0.7Mpa;
Rated Working Pressure: 0.5Mpa;
25% Liquid Drain Time : ≥ 120 s;
Surface Finishing : Epoxy Fire Red.
| Model Number | Type | Flow Rate | Inlet Size | Outlet Size |
| PCL4 | Low Expansion,vertical | 240LPM | 50mm(2'') | 80mm (3'') |
| PCL8 | Low Expansion,vertical | 480LPM | 65mm(2.5'') | 100mm(4'') |
| PCL16 | Low Expansion,vertical | 960LPM | 80mm (3'') | 150mm(6'') |
| PCL24 | Low Expansion,vertical | 1440LPM | 100mm (4'') | 200mm (8'') |
FAQ
Q1. Can I have a sample order?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A:Sample needs 7-15 days, mass production time needs 30-40 weeks for order quantity more than 1 container.
Q3. Do you have any MOQ limit?
A: For conventional products, Low MOQ, OEM products request 30-40days.
Q4. Is it OK to OEM ?
A: Yes. Please inform us formally before our production and confirm the design and other requirements firstly .
Q5. Do you offer guarantee for the products?
A: Yes, we offer 1 year warranty to our products.
Order Information
Dear Customer,
Before ordering, please contact with our sales team to discuss order information, such as Model Number, Flow Rate, Material,Control Ways, Package,Etc.
If you have any other requirements or wanna know more info about our products, welcome to contact as well. Our Sales team and Technical Department are willing to support you.
