Products Description
FOREDE ® PSKD8/20-40W-C Series cannon/monitor is electric wired (or wireless remote control) DC drive,Water truck water cannon is an amazing invention that has revolutionized the way we fight fires and clean our streets. These powerful machines are capable of pumping out water at high pressure and can easily reach heights of over 50 feet in the air. Whether you need to put out a wildfire or clean up a construction site, water truck water cannons are an essential tool for any job.
Technical Product parameters
|
Model Number |
PSKD8/20W-C |
PSKD8/30W-C |
PSKD8/40W-C |
PSKD8/20-40W-C |
|
Flow Rate |
1200 LPM Constant Flow |
1800 LPM Constant Flow |
2400 LPM Constant Flow |
1200-1800-2400 LPM Selectable Flow |
|
Working Pressure |
8 Bar |
8 Bar |
8 Bar |
8 Bar |
|
Max. Reach |
50 meters |
60 meters |
65 meters |
50-65 meters |
|
Max. Fog Angle |
120° |
|||
|
Max Range Of Motion |
-35° to +85° Vertically, 340° Rotation,other degree available |
|||
|
Power Supply |
DC 24V is standard |
|||
|
Power Consumption |
≤200W |
|||
|
Waterway Size |
2 1/2" (65mm) |
|||
|
Monitor Outlet |
2 1/2" (65mm) NH male thread |
|||
|
Monitor Inlet |
Flange 2.5" ANSI 150# is standard,other size and standard available |
|||
|
Material |
Monitor & Nozzle- Hard coated anodized aluminium alloy |
|||
|
Control System |
ICS-01 or VMCS-01 |
|||
FAQ
Frequently Asked Questions
Q: How long does it take to produce the product?
+
-
A: Generally speaking, it isn't a large-scale purchase, and the lead time about 15 working days.Of course, having an urgent order, please reconfirm with us.A: Conventional products and small quantities can be produced within 15 days. The specific production time needs to have specific products and product quantities to confirm.
Q: Whether the product supports OEM customization
+
-
A: Yes. Please inform us formally before our production and confirm the design and other requirements firstly .
Q: How water pressure important?
+
-
A: Water pressure controls how far and how fast water moves as well as how deeply water penetrates burning materials. For firefighting, more flow rate of water available means more extinguishing agent to cool the fire's fuel. Each nozzle has an expected, or rated, gallonage at a rated pressure. For example, a nozzle may deliver 60 LPM at 6 Bar, and 475LPM at 7 Bar.
Q: What is your term and payment?
+
-
Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shipment.
Q: Can you accept OEM?
+
-
A:Yes, we do customized design for our clients.
Factory View
forede Water Truck Parts Series
01
Electric Water Cannon
02
Manual Water Cannon
03
Rotating Joint
Contact Us
Hot Tags: water truck parts water cannon, China, manufacturers, suppliers, wholesale, price, Flanged Underground Square Head Gate Valve, Sidewall Water Spray Nozzle, Fire Fighting Monitor With Remote Control, Two Way Pillar Fire Hydrant, Automatic Fire Water Cannon, Check Valve
- Aluminium alloy construction,hard anodized;
- Constant or Selectable flow rate;
- Vertical travel of 120°,from -35° to +85°;
- 340° rotation horizontally;
- Electric control jetting Pattern: Straight stream,Fog;
- Electric.driver and control unit box are waterproof;
- Optional power supply 12V/24V DC(optional),or 100-230AC.
