A manual fire monitor is an essential tool used in the firefighting industry. It is a device that enables firefighters to regulate and direct water from a stationary position to extinguish fires more effectively. Manual fire monitors come in different sizes and can discharge huge amounts of water, ranging from 500 to 5000 gallons per minute.
These devices are usually mounted on the back of fire trucks and operated by firefighters at the scene. They are simple to operate and require only minimal training. Manual fire monitors also offer an added level of safety to firefighters, as they allow them to tackle fires from a safe distance.
Max.Flow Rate
Flow Style
Max.W. Pressure
Max. Reach @ 8 bar
product parameters
|
Model |
TFS1.AF020 |
TFS1.AF030 |
TFS1.AF040 |
TFS1.AS040 |
|
Flow Rate |
1200LPM |
1800LPM |
2400LPM |
1200-1800-2400LPM |
|
Working Pressure |
0.8 MPa |
0.8 MPa |
0.8 MPa |
0.8 MPa |
|
Max Working Pressure |
1.6 MPa |
1.6 MPa |
1.6 MPa |
1.6 MPa |
|
Throw Range(water) |
≥ 50 m |
≥ 60 m |
≥ 65 m |
≥ 50-65 m |
|
Throw Range(foam) |
≥ 45 m |
≥ 55 m |
≥ 60 m |
≥ 45-60 m |
|
Horizontal Angle |
0°~330° (angle customized) |
|||
|
Elevation Angle |
-45°~+75° (angle customized) |
|||
|
Waterway Size |
2.5'' (DN65mm) |
|||
|
Outlet |
2.5'' NH |
|||
|
Inlet |
3''/4'' BS4504 PN16 Flange, others customized |
|||
do you have any question?
Q. Do your offer free sample for your clients?
A: Yes, we offer free sample for many of the products
Q. What's the MOQ of your products?
A: Our MOQ is one (1) piece/set.
Q. What's your payment terms?
A: We accept T/T, L/C, Western Union, Paypal,etc.
Q. How long is the delivery time?
A: Usually around 15 days after payment.
