forede® FRD-HR combined hose rack and landing valve cabinets are generally fabricated from stainless steel material. The door hinges are either riveted or welded to the cabinet and swings out 180 degree from left to right. The cabinet comes with viewing panel design at the door to show the equipment installed insideThe quality of workmanship and finishes are carefully planned and executed from the initial stage of preparing the material, fabrication, up to the surface preparation and powder coating.

The combined hose rack and landing valve cabinet standard finishes of the Stainless steel Type 304 or 316 cabinets come with good quality. Other finishes available on request.

Features

Product Name: Combined hose rack and landing valve cabinet

Capacity: Hose rack assembly + landing valve

Surface: Red powder coating / bright SS

Dimension W x H x D: 700 x 800 x 200mm

Mounting: Wall surface

Products Parameters

forede® combined hose rack and landing valve cabinets different size and standard for option:

Model	Capacity	Mounting	Dimension W x H x D (mm)
FRD-HR01	1.5" x 30m + DN 65	Surface	700 x 800 x 200
FRD-HR02	As customized	Surface	As customized

FAQ

Q: What kind of the lock of this combined hose rack and landing valve cabinet?

The lock include types: Mainly rotary pull lock, push button bounce lock, or keyed cylinder lock.

Q:What kind of the door type of combined hose rack and landing valve cabinet?

The model FRD-HR combined hose rack and landing valve cabinet with single door, from left to right open 180°, bullet hinge or continuous piano hinge.

Q: What is the standard of the assembly in the combined hose rack and landing valve cabinet?

Combined hose rack and landing valve cabinet has both American and British standard feature.

Q: How long of the fire hose in the combined hose rack and landing valve cabinet?

The length of the fire hose is customizable, from 12-50m for options.

Q: Where is the combined hose rack and landing valve cabinet used?

The combined hose rack and landing valve cabinet, as the name suggests, combines a hose rack and a landing valve in one compact unit. This equipment is used to store fire hoses and provides quick and easy access to the water supply in the event of a fire emergency. The cabinets are often installed near exits or stairwells, ensuring that the hoses are easily accessible and can be deployed quickly to contain the fire.
