Products Description
Overview
forede® JPAAS550 manual swing type fire hose reel A manual fire hose reel is a firefighting device designed to store and deploy a hose that delivers water to extinguish fires. Unlike automatic or motorized systems, a manual fire hose reel requires human operation to unwind and control the hose flow.
Reel Drum: Holds the hose in a coiled form for easy storage.
Hose: Usually made of durable synthetic material or rubberized fabric capable of handling high-pressure water.
Nozzle: Controls the water spray pattern (jet or spray).
Frame Bracket: Supports the reel and allows wall or floor mounting.
Manual Crank (optional): For rewinding the hose after use.
Features
Hose Reel Type: Manual swing type fire hose reel.
Inlet Valve Type: Ball Valve, Gate Valve, BSP Thread(Standard).
Working Pressure: 1.2Mpa.
Max Working Pressure: 1.8Mpa.
Drum Surface Finishing: Red powder coating.
Use with JPSQ01 nozzle, Red reel hose.
Products Parameters
forede® manual swing type fire hose reel with different size and standard for option:
| Part Number | JPAAS550-19-25 | JPAAS550-19-30 | JPAAS550-25-25 | JPAAS550-25-30 |
| Disc Diameter | 550 mm | 550 mm | 550 mm | 550 mm |
| Inlet Connection | 1" BSP | 1" BSP | 1" BSP | 1" BSP |
| Reel Hose Size | 3/4" | 3/4" | 1" | 1" |
| Reel Hose Length | 25m | 30m | 25m | 30m |
| W.Pressure | 12 Bar | 12 Bar | 12 Bar | 12 Bar |
FAQ
Q: What are the main components?
Hose reel drum: Holds the fire hose.
Swing arm / pivot arm: Allows the reel to rotate horizontally.
Mounting bracket: Secures the reel to a wall or structure.
Fire hose: Usually made of rubber or synthetic fabric, rated for firefighting pressure.
Nozzle: Controls the water flow and spray pattern.
Q: What types of hoses are used?
Typically, hoses for swing arm reels are lightweight, flexible, and durable, rated for high-pressure water delivery. They can be standard fire hoses (1"–1.5" diameter) or hoses specifically designed for indoor/outdoor use.
Q: What are the advantages of a swing arm hose reel?
Wide coverage: The swing arm allows easy rotation to reach different areas.
Quick deployment: Hose can be extended and retracted quickly in emergencies.
Space-saving: Mountable on walls or columns, reducing floor space usage.
Reduced hose wear: Controlled retraction prevents kinking and damage.
Q: Where are swing arm fire hose reels typically used?
Industrial facilities
Warehouses
Commercial kitchens
Workshops and factories
Areas where fire hazards exist and hose flexibility is needed
Q: How is it installed?
Mount the bracket securely to a structurally strong wall or column.
Attach the swing arm and hose reel to the bracket.
Connect the hose inlet to a pressurized water source.
Ensure the arm rotates freely and the hose can be pulled out without obstruction.
