Explosion Proof Fire Auomatic Remote Control Monitor
ZDMS0.8 EX Explosion Proof Automatic Fire Water Monitor Cannon is an organic combination of image processing and transmission technology, ultraviolet sensing technology, signal processing technology, communication control technology, computer technology and mechanical transmission technology, which can automatically monitor special places all-weather Fire within the protection area. Once a fire occurs, the device is immediately activated, and the fire source is scanned and positioned horizontally and vertically. After determining the two positions of the fire source, the central controller sends out a fire alarm signal, starts the water pump, opens the valve, and aligns the fire extinguishing device. The fire source carries out water jetting to extinguish the fire. After the fire source is extinguished, the central controller sends an instruction to stop water jetting. If there is a new fire source, the fire extinguishing device will repeat the above process, and return to the monitoring state after all fire sources are extinguished.
estinguisher
Working Pressure
Optional
Warranty
| ZDMS0.6 Automatic Fire Monitor | ||
|
Model
|
ZDMS0.8 /20S-W
|
ZDMS0.8 /30S-W
|
|
Control
|
Automatic,Control box,Field manual
|
Automatic,Control box,Field manual
|
|
Rated Flow
|
20 LPS
|
30 LPS
|
|
Working Pressure
|
8 Bar
|
8 Bar
|
|
Jet Radius
|
56 m
|
62 m
|
|
Max Protection Radius
|
50 m
|
55 m
|
|
Monitoring Radius
|
80 m
|
|
|
Horizontal Rotation Angle
|
360°
|
|
|
Vertical Rotation Angle
|
-90°~+30°
|
|
|
Mounting Height
|
8~15 m
|
|
|
Targeting Time
|
≤60S
|
|
|
Communication Mode
|
RS485
|
|
|
Detector Type
|
Infrared ray&UV sensor technology
|
|
|
Inlet
|
2.5''BS Flange, others size and standard available
|
|
|
Power Consumption
|
Monitoring 1W,Detecting 50W
|
|
|
Part Name
|
Quantity
|
Remarks
|
|
Automatic Fire Monitor
|
1
|
|
|
Control Box
|
1
|
Switch operation mode Automatic/Manual
|
|
Signal Decoder
|
1
|
Convert the signal into the information it represents
|
|
Solenoid Valve
|
1
|
Control fluid automation infrastructure components
|
|
Camera(optional)
|
1
|
Video Surveillance
|
Frequently Asked Questions
Q. How do you deliver the goods and how long does it take to arrive?
-
A: We usually deliver mass order by sea and air, delivery time is depended on the carrier,urgent trail order usually deliver by
DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Railway also optional.
Q. Is it OK to OEM ?
-
A: Yes. Please inform us formally before our production and confirm the design and other requirements firstly .
Q: Do you offer guarantee for the products?
-
A: Yes, we offer 1 year warranty to our products.
Q.Can I have a sample order?
-
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable
Q. What about the lead time?
-
A:Sample needs 15-20 days, mass production time needs 30-40 weeks for order quantity more than 1 container.
Main Product:
Order Information:
Dear Customer,
Before ordering, please contact with our sales team to discuss order information, such as Model Number, Flow Rate, Material, Control Ways, Package,Etc.
If you have any other requirements or wanna know more info about our products, welcome to contact as well. Our Sales team and Technical Department are willing to support you
Hot Tags: explosion proof fire auomatic remote control monitor, China, manufacturers, suppliers, wholesale, price, Automatic Scanning Fire Monitor, Dry Type Sprinklers, FM 200, Automatic Fire Monitor Water Cannon, Standard Spray Sprinkler Head, Fixed Manual Fire Monitor
1) Hard anodized aluminium alloy constrcution;
2) Iaser positioning indication, high-definition screen monitoring;
3) Straight stream＆Fog or Straight stream nozzle;
4) Vertical travel of 120°,from -90°to+30°
5) Electric control jetting pattern: Straight stream,Fog
6) Eletric.driver and control unit box are waterproof;
7) Optional power supply 12V/24V DC(optional),or 100-230AC
