Products Description
The Fire Monitor Cannon Water Monitor For Fire is a modern fire-fighting equipment that can use advanced technology to greatly improve the efficiency of fire extinguishing and effectively prevent the occurrence of fires.
This kind of Fire Monitor Cannon Water Monitor For Fire can realize fast and accurate fire source positioning, and can also be automatically controlled to achieve fire extinguishing. At the fire scene, the fire extinguishing equipment will automatically detect information such as ambient temperature, smoke concentration, and flame, and automatically start the fire extinguishing equipment.
There are many advantages to self-seeking fire extinguishing devices. First, it can automatically search for fire sources and start fire extinguishing equipment immediately after discovering fire sources. Secondly, it can extinguish fires in the early stages of fires, prevent the spread of fires, and reduce losses caused by fires. In addition, it can promptly notify the fire rescue department and help rescue personnel achieve rapid response. Most importantly, this equipment protects people's lives and property.
In short, the Fire Monitor Cannon Water Monitor For Fire is a very important fire-fighting equipment. It adopts advanced technology to improve the efficiency of fire extinguishing, prevent the occurrence of fires, and protect people's lives and property safety.
Technical Parameter
| Model | ZDMS0.6/ 5S | ZDMS0.8/ 10S | ||
|
Flow Rate |
300 LPM | 600 LPM | ||
|
Working Pressure |
6 Bar | 8 Bar | ||
| Max protection radius | 30 meters | 35 meters | ||
| Monitoring radius | 50 meters | 50 meters | ||
|
Installation Height |
advice 6-15m | |||
| tartgeting time | ≤30 S | |||
|
Max Range Of Motion |
-90° to +30° Vertically, 360° Rotation | |||
| Power supply | AC 220V is standard | |||
|
Monitor Outlet |
14 mM | 19.5 MM | ||
|
Monitor Inlet |
Flange 2" BS4504 is standard ( other sizes & standards are available ) | |||
|
Material |
Monitor & Nozzle - Hard coated anodized aluminium alloy | |||
| Detector type | infrared ray | |||
| Communication Mode | RS485 | |||
FAQ
01. What's the MOQ?
02. How to get the price?
03. What's the production time?
04. How long the warranty time? Can we buy spare parts in the future for replacement?
05. Does it support customization?
06. What are the shipping methods and fees for the goods?
Contact US
Our address
NO.278-1, MEITING VILLAGE, MEILIN SUB-DISTRICT, NAN'AN CITY, QUANZHOU CITY, FUJIAN PROVINCE, CHINA.
Phone Number
0086-13107856309 (whatsApp)
About US
QUANZHOU FOREDE FIREFIGHTING EQUIPMENT CO.,LTD.
Since company was found in 2003, FOREDEFIRE has evolved and grown from a small factory in the yard with the limited capacity to only make sprinklers, to a sophisticated and leading company.
In 2013, FOREDEFIRE establish production base in Sanduo Industry Park, Jiangsu PRC to develop and improve fire monitor, fire nozzle, foam system device, fire robot etc. Increased production and enhanced quality and cost control to accommodate our continuing growth
large enterprise scale
Efficient and precise processing and testing equipment.
Standardized Production
Passed ISO9001, CE certification and obtained relevant patent certificates.
High-Quality Customized Services
No intermediate links, providing one-stop service from design, processing, mold trial to mass production.
Work Shop View - Fire Nozzle & Monitor
Hot Tags: fire monitor cannon water monitor for fire, China, manufacturers, suppliers, wholesale, price, Fixed Manual Fire Monitor, Automatic Fire Monitor Water Cannon, Positioning Fire Water Monitor, Automatic Fire Water Cannon, Remote Control Water Cannon, Standard Spray Sprinkler Head
- Hard anodized aluminum alloy construction
- Straight Stream nozzle
- Vertical travel of 120°,from -90° to +30°
- 360° rotation horizontally
- Optional power supply 100-230AC
