Dual HandWheel Foam Water Monitors

Dual HandWheel Foam Water Monitors
Product Introduction:
Dual HandWheel Foam Water Monitor is a stationary firefighting tool with dual water and foam suppression functions, controlled by two independent handwheels. The dual-handwheel design enables separate adjustment of direction/angle and flow rate/medium switching, allowing flexible and targeted fire suppression without relying on electrical or pneumatic power, ensuring reliability in various emergency environments. forede model offers selectable flow rates of 24/32/40 LPS, with water range of 55/60/65 meters and foam range of 42/48/55 meters. It adapts to different fire types—using water for solid fires and foam for flammable liquid fires to achieve efficient suppression. Crafted from durable lightweight materials, it supports 360-degree rotation and flexible vertical adjustment for full coverage. Suitable for industrial areas, ports, and petrochemical sites, it is an easy-to-operate, versatile solution for large-area fire protection with dual-medium capability.
Send Inquiry
Description
Technical Parameters

Products Description

Dual HandWheel Foam Water Monitors





Forede Dual HandWheel Foam Water Monitor is customized to meet diverse firefighting demands, featuring selectable flow rates of 24/32/40 LPS. It delivers different range performances based on media type: water reaches 55/60/65 meters, while foam range achieves 42/48/55 meters. This parameter combination allows operators to engage fires from a safe distance, adapting to different fire scales and fuel types-using water for general fires and foam for flammable liquids to smother flames and prevent re-ignition. Made of lightweight and sturdy materials, this monitor supports 360-degree horizontal rotation and smooth vertical adjustment, ensuring full coverage of the protected area. Its seamless switching between water and foam modes enhances versatility, suitable for installation in industrial parks, warehouses, ports, airports, and petrochemical facilities. The Forede Dual HandWheel Foam Water Monitors combine intuitive operation with high adaptability, providing a cost-effective and reliable fire protection solution for large-area spaces requiring dual-medium suppression.

-1


Features:
  SS304 Stainless Steel Construction;
  Handwheel Control;
  Flow Rate: 20/30/40 LPS (Optional);
  Flange standard: BS4504,ANSI150,GB,etc.
  Nozzle Material:SS304+Aluminium Alloy;

Manual

Handle


0.8Mpa

Working Pressure


Water

Medium


1 Year

Warranty

Specification


Technical Parameters
Model Number WFS1.AP024 WFS1.AP032 WFS1.AP040
Flow Rate 1440LPM 1920LPM 2400LPM
Working Pressure 8 bar 8 bar 8 bar
Max.Reach@8 Bar Water 55 Meters 60 Meters 65 Meters
Max.Reach@8 Bar Foam 48 Meters 48 Meters 55 Meters
Max Range of Motion
-45° to +75° Vertically, 360° Rotation
Waterway Size 2.5''(65mm)
Monitor Outlet
2.5"(65mm) NH male thread
Monitor Inlet
Flange 3" ANSI 150 is standard ( other sizes & standards are available )
Material
Monitor - SS304 Stainless Steel
Nozzle - SS304 Stainless Steel+Aluminium Alloy
Handwheel -Aluminium Alloy



Detail Pictures
QQ2026011416361570
QQ2026011416361571
frequently Asked Question
Frequently Asked Questions



Q:What is the production time of the sample?



-

A:A sample will be produced within 15 days.

Q.How can I get the price?



-

A:We usually quote within 24 hours after we get your inquiry(Except weekend and holidays).If you are very urgent to get the price, please email us or contact us in other ways so that we can offer you a quote.

Q. Can I buy samples placing orders?



-

A: Yes.Please feel free to contact us.

Q.What is the shipping method?



-

A: It could be shipped by sea,by air or by express(EMS,UPS,DHL,TNT,FEDEX and ect). Please confirm with us before placing orders.

Q.How do you make our business long-term and good relationship?



-

A: We keep good quality and competitive price to ensure our customers benefit and respect every customer as our friend and we sincerely do business and make friends with them,no matter where they come from.
