Handwheel Firefighting Water Monitor

Product Introduction:

The FOREDE® Brand PS10/30-50W-H as Fire Fighting Monitor, it provides good long jet range and stable quality, the fire monitor nozzle flow rate from1800 LPM up to 3000 LPM. A lightweight and highly durable flow-efficient monitor due to the Aluminum Alloy with Hard Anodized workmanship. PS30-50H with few and easy maintenance, suitable for good range of Industries.

Send Inquiry

Description

Technical Parameters

The FOREDE® Brand PS10/30-50W-H as Fire Fighting Monitor, it provides good long jet range and stable quality, the fire monitor nozzle flow rate from1800 LPM up to 3000 LPM.

A lightweight and highly durable flow-efficient monitor due to the Aluminum Alloy with Hard Anodized workmanship. PS10/30-50W-H with few and easy maintenance, suitable for good range of Industries.

The specification please see following:

Model Number	PS10/30-50W-H
Material	Aluminum alloy
Flow Rate	1800-2400-3000LPM Adjustable Nozzle
Working pressure	10 bar
Max. Reach@10 bar	65meters@3000LPM
Max. Fog angle	120°
Range of the monitor	360°horizontal rotation,-45°/+90°vertical elevate
Water way	2.5(65mm)"
Inlet	Flange 4''BS4504 is standard ,other standard flange is available
Outlet	2.5"(65mm) NH male thread
Material	Monitor＆Nozzle-aluminium alloy Handwheel-Aluminium or Ductile Iron

FAQ :

Q: What is fire nozzle?

A:According to the function and parts, fire nozzle can be divided into nine types, they are jet spray fire nozzle, shut-off fire nozzle, multifunctional fire nozzle, selectable flow fire nozzle,automatic fire nozzle, defense fire nozzle, piercing applictor fire nozzle, and waterwall fire nozzle, foam nozzle.

Q:What about the lead time?

A:Sample needs 7-15 days, mass production time needs 30-40 weeks for order quantity more than 1 container.

1.Q: How To Order ?

A: Step 1, please tell us what model and quantity you need;

Step 2, then we will make a Pl for you to confirm the order details; Step 3, when we confirmedeverything, can arrange the payment; Step 4, finally we deliver the goods within the stipulated time.

Hot Tags: handwheel firefighting water monitor, China, manufacturers, suppliers, wholesale, price, Fixed Water Monitor, Manual Foam Monitor, Fire Truck Fire Monitor, Water Monitor Fire Fighting, Fire Water Cannon, Elevated Fire Water Monitor

1) Aluminium alloy construction.

2) Flow Rate ajustable.

3) Jetting Patternl :Straight Stream,Fog.

4) 360°Rotation horizontally,-45°/+90°Elevate vertically

5) Easy to service and repair.

6) Flange standard:BS4504,ANSI150,GB,etc
