Handwheel Water Foam Monitor
The FOREDE® Brand WFS2.AZ4 as Fire Fighting Monitor, it provides good long jet range and stable quality.
WS2.AZ4 with few and easy maintenance, suitable for good range of Industries.
Model | WFS2.AZ4 | ||||
Flow Rate | 2230-4800LPM Adjustable | ||||
Working pressure | 10 Bar | ||||
Water Jetting Range | 70 meters @3000LPM | ||||
Rotation Horizontally | 360° | ||||
Elevate Vertically | -45° to +90° | ||||
Inlet | DN100 (4") | ||||
Outlet | 2.5" NH | ||||
OPERATIONAL REQUIREMENTS AND PRECAUTIONS:
- The personnel operating the fire monitor must be trained in operation and be familiar with the relevant operation process.
- The inlet pressure of water shall not be higher than the working pressure of the monitor.
- Before using the fire monitor, all personnel in front of the muzzle should be evacuated to avoid danger.
- When manually operating the fire monitor, please take the handle to avoid danger.
- When operating, it should be jetted downwind as far as possible to increase the range.
FAQ:
Q: What is the minimum order quantity of the product?
A:For conventional products, Low MOQ.
Q:Can I have a sample order?
A:Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q: How do you deliver the goods and how long does it take to arrive?
A:We usually deliver mass order by sea and air, delivery time is depended on the carrier,urgent trail order usually deliver by DHL, UPS, FedEx or TNT. It usually takes 5-7 days to arrive. Railway also optional. In fact, the delivery method depends on the quantity.
Hot Tags: handwheel water foam monitor, China, manufacturers, suppliers, wholesale, price, Foam Monitor Fire Fighting, Elevated Fire Monitor, Elevated Fire Water Monitor, Fire Monitor Water Cannon, Industrial Fire Monitors, Standard Response Standard Spray Sprinklers
1) 304 Stainless Steel construction;
2) Double Hand wheel Control;
3) Flow Rate: 1200-3000LPM (optional);
4) Available for water and foam both;
5) 360° rotation horizontally;
6) -45° to +90° elevate vertically;
7) Flange standard: BS4504,ANSI150,GB,etc.
