Products Description
Overview
forede® TFS1.SS040 SS316 manual fire water monitor with full 2.5" waterway provides flows of up to 20-30-40 LPS and can be used with a choice of forede monitor nozzles to suit a wide range of specific applications. With full 360° rotation capabilities and adjustable elevation of 90° above and 60° below the horizontal, TFS1.SS040 fixed station monitor is infinitely maneuverable via the wheels. Vertical and Horizontal quick-action locks allow the operator to fix the monitor swiftly to any position.
Core Advantages:
- Excellent salt water & acid alkali corrosion resistance, long service life
- Pure manual design, safe and reliable in power failure situation
- Easy installation, flexible direction adjustment
- Compatible with fire foam system for oil fire fighting
- Low failure rate, simple daily maintenance
Features
Product Name: Fixed station water cannon
Flow Rate: 1200-1800-2400 LPM
Jetting Pattern: Straight stream, Fog
Max. Reach: 65 meters
Products Parameters
forede® SS316 manual fire water monitor with different size and standard for option:
|
Model Number |
TFS1.SF020 | TFS1.SF020 | TFS1.SF030 | TFS1.SS040 | ||||||||||||
|
Flow Rate |
1200LPM | 1800LPM | 2400LPM | 1200-1800-2400LPM | ||||||||||||
|
Working Pressure |
8 Bar |
8 Bar | 8 Bar | 8 Bar | ||||||||||||
|
Max. Reach |
≥ 50 m | ≥ 60 m | ≥ 65 m | ≥ 50-65 m | ||||||||||||
|
Max Range Of Motion |
-45° to +75° Vertically, 330° Rotation, other degree available |
|||||||||||||||
|
Waterway Size |
2.5'' (DN65mm) | |||||||||||||||
|
Monitor Outlet |
2.5'' NH | |||||||||||||||
|
Monitor Inlet |
3''/4'' BS4504 PN16 Flange, others customized | |||||||||||||||
|
Material |
Monitor - SS316 Nozzle - SS316+Brass |
|||||||||||||||
FAQ
Q: What material is this fire water monitor?
Full body made of SS316 stainless steel, superior seawater corrosion resistance.
Q: Is it manual operation type?
Yes, operated by handwheel, no power supply required, easy to control.
Q: What is the working pressure?
Rated working pressure 1.0MPa, max test pressure 1.6MPa.
Q: Can adjust water spray mode?
Support straight stream and fog spray two modes, easy switching.
Q: What is the effective shooting range?
Effective distance up to 60-80 meters under standard pressure.
