Fire Monitor with Control

Fire Monitor with Control
Product Introduction:
Explosion Proof Remote Control Fire Monitor is an essential firefighter equipment that has proven to be highly effective in fighting fires in hazardous and explosive environments. It is a vital tool for ensuring the safety of workers and protecting property in industries where fire hazards are an ever-present danger.
Send Inquiry
Description
Technical Parameters



1



What is Explosion Proof Remote Control Fire Monitor ?

Explosion Proof Remote Control Fire Monitor is a specialized device designed to tackle fires in hazardous and explosive environments. It is equipped with a remote control system that enables it to be operated safely from a distance, keeping the operator out of harm's way and minimizing the risk of injury. The fire monitor is made of high-quality materials that are resistant to corrosion, explosion, and extreme temperatures.





It is also designed to be highly versatile, with the ability to be mounted on a variety of surfaces and adjusted to different angles. Its powerful jets of water or foam can quickly extinguish a fire, preventing major damage and providing a safe environment for workers. Overall, the Explosion Proof Remote Control Fire Monitor is an essential tool that can save lives and protect assets in high-risk environments.











4800

Max.Flow Rate





Constant

Flow Style





10.5 Bar

Max.w. Pressure





120°

Max. Fog Angle





 product parameters







Flow Rate
3000/3600/4800LPM Constant Flow
Max. Reach @ 8 bar
70/75/85 Meters
Working Pressure
8/9.5/10.5 Bar
Max Range Of Motion
-45° to +90° Vertically, 360° Rotation,other degree available
Turing Speed
7°/Second rotation,7°/Second vertical
Power Supply
DC 24V is standard
Power Consumption
Max. 195W
Waterway Size
2.5" (65mm) /3"(80mm)
Monitor Outlet
2.5" (65mm) NH
Monitor Inlet
Flange 4" ANSI 150# is standard,other size and standard available
Material
Monitor - SS304 stainless steel is standard,SS316 is available
Nozzle - Hard coated anodized aluminium alloy
Control System
ICS-EX-01 or VMCS-01






do you have any question?

1



Q. Do your offer free sample for your clients?

A: Yes, we offer free sample for many of the products



Q. What's the MOQ of your products?

A: Our MOQ is one (1) piece/set.



Q. What's your payment terms?

A: We accept T/T, L/C, Western Union, Paypal,etc.



Q. How long is the delivery time?

A: Usually around 15 days after payment.






forede® Fire Monitor System Series
图片尺寸 210x210
Title
Title
Title
Title
图片尺寸 210x210
Title
Title
Title
Title







forede® Main Products

How to contact us?
How To Cooperate With Us?

Our address

Nan'an City, Quanzhou City Fujian PRC-china

Phone Number

2





Hot Tags: Fire Monitor with Control, China, manufacturers, suppliers, wholesale, price, Early Suppression Fast Response Sprinklers, Defense Type Fire Hose Nozzle, Fixed Water Cannon, Pistol Grip Selectable Fire Nozzle, Remote Control Fire Water Cannon, Remote Water Foam Monitor



Features:
304L stainless steel construction;
- Constant flow nozzle;
- Vertical travel of 135°,from -45°to +90°;
- 350°rotation horizontally;
- Electric control jetting Pattern: Straight stream,Fog;
- Explosion proof class IICT4;
- Optional power supply 24V DC(optional), or 100-230 V AC;
- Flow Rate 3000/3600/4800 LPM.
