Technical Parameter
| Model |
PSKD10/50WG-A
|
PSKD10/60WG-A
|
PSKD10/80WG-A
|
|
Flow Rate
|
3000LPM Automatic Flow | 3600LPM Automatic Flow | 4800LPM Automatic Flow |
| Working Pressure | 10 Bar | ||
|
Max. Reach
|
70 meters
|
75 meters | 85 meters |
|
Max. Fog Angle
|
120°
|
||
|
Max Range Of Monitor
|
-60° to +90° Vertically, 360° Rotation,other degree available
|
||
|
Power Supply
|
DC 24V is standard
|
||
|
Power Consumption
|
Max. 195W
|
||
|
Waterway Size
|
3"(80mm))
|
||
|
Monitor Outlet
|
2.5" (65mm) NH
|
||
|
Monitor Inlet
|
Flange 4" ANSI 150# is standard,other size and standard available
|
||
|
Material
|
Monitor - SS304 stainless steel is standard,SS316 is available
Nozzle - Hard coated anodized aluminium alloy
|
||
|
Control System
|
ICS-EX-01 or VMCS-01
|
||
What are the advantages of Explosion Proof Remote Control Fire Monitor
The explosion-proof remote control fire monitor is a highly advanced firefighting tool that offers several advantages. Here are some of them:
Increased Safety
As the name suggests, this fire monitor is engineered to be explosion-proof. Its design and construction prevent any ignition or explosion even in hazardous or flammable environments, making it a safe choice for firefighting in industrial settings.
Efficiency
The remote control feature of this fire monitor allows operators to control it from a distance. The ability to maneuver the monitor from a safe distance allows operators to extinguish fires quickly and effectively.
Versatility
Explosion-proof remote control fire monitors are versatile tools that can be used in different firefighting scenarios. They can be mounted on different types of vehicles or vessels, making them useful in various environments.
Durability
The fire monitor is made from durable materials that can withstand the harsh conditions of industrial settings. It is resistant to corrosion, high temperatures and chemicals that are common in such environments.
Range
The fire monitor has an excellent range and can elicit a spray of water up to 100 meters long. This makes it highly effective for larger industrial fires, as it can reach areas that are difficult to access otherwise.
Rapid Response
With its powerful water spray, the explosion-proof remote control fire monitor is equipped to handle dangerous fires quickly and effectively. Its remote control feature enables operators to respond rapidly to emergency situations and help prevent a disaster from occurring
do you have any question?
Q. Do your offer free sample for your clients?
A: Yes, we offer free sample for many of the products
Q. What's the MOQ of your products?
A: Our MOQ is one (1) piece/set.
Q. What's your payment terms?
A: We accept T/T, L/C, Western Union, Paypal,etc.
Q. How long is the delivery time?
A: Usually around 15 days after payment.
