Technical Parameter
| Model |
PSKD10/50WG-AC
|
PSKD10/60WG-AC
|
PSKD10/80WG-AC
|
|
Flow Rate
|
3000LPM Constant Flow | 3600LPM Constant Flow | 4800LPM Constant Flow |
| Working Pressure |
10 Bar
|
||
|
Max. Reach
|
70 meters
|
75 meters | 85 meters |
|
Max. Fog Angle
|
120°
|
||
|
Max Range Of Monitor
|
-60° to +90° Vertically, 350° Rotation,other degree available
|
||
|
Power Supply
|
AC 380 V
|
||
|
Power Consumption
|
Max. 195W
|
||
|
Waterway Size
|
3"(80mm)
|
||
|
Monitor Outlet
|
2.5" (65mm) NH
|
||
|
Monitor Inlet
|
Flange 4" ANSI 150# is standard,other size and standard available
|
||
|
Material
|
Monitor - SS304 stainless steel is standard,SS316 is available
Nozzle - Hard coated anodized aluminium alloy
|
||
|
Control System
|
ICS-EX-01 or VMCS-01
|
||
What are the advantages of Explosion Proof Remote Control Fire Monitor
Explosion-proof remote control fire monitors are highly advantageous when it comes to effectively and safely fighting fires in hazardous environments. Here are six top benefits of such monitors:
Safe Operation
The use of an explosion-proof remote control system ensures safe operation of the fire monitor. It prevents any potential accidents resulting from the operator's proximity to hazardous areas or the occurrence of an explosion.
High Efficiency
These monitors have high water flow rates and discharge pressure, making them ideal for tackling big fires in a relatively short amount of time.
Robustness
Explosion-proof remote control fire monitors are built to withstand harsh conditions and are designed to last a long time, making them a valuable investment.
Versatility
These monitors are highly versatile and are suitable for a wide range of applications, including offshore oil rigs, chemical plants, and fuel storage facilities.
Precise Control
An explosion-proof remote control system provides precise control over the fire monitor's movement and discharge pattern, which makes extinguishing the fire more efficient and effective.
Improved Safety
The use of an explosion-proof remote control system reduces the need for personnel to be present during the firefighting process, thus reducing the risks of injuries and fatalities. It also eliminates the risk of a secondary fire outbreak in the event of an explosion.
do you have any question?
Q. Do your offer free sample for your clients?
A: Yes, we offer free sample for many of the products
Q. What's the MOQ of your products?
A: Our MOQ is one (1) piece/set.
Q. What's your payment terms?
A: We accept T/T, L/C, Western Union, Paypal,etc.
Q. How long is the delivery time?
A: Usually around 15 days after payment.
