Products Description
Selectable Fire Flow Nozzle
The QLD6.0/1.0III Fire Handline Nozzle With Flow Settings has a selectable flow range at 6 bar of 15,30,45 and 60 litres per minute to meet the individual needs of the fire fighter at any given time but alternative flow rates are available.
- Flow Rate:15 - 30 - 45 - 60 LPM - Flush (Selectable);
Flow Rate
working pressure
Max.Reach@6Bar
warranty
Specification
| Model | Material | Inlet Size | Working Pressure | Max. Reach | Max. Fog Angle |
| QLD6.0/1.0III-25 | Hard Anodized Aluminium Alloy | 1''/25 mm | 6 bar | 35 m @ 6 bar | 110° |
| QLD6.0/1.0III-25 | Hard Anodized Aluminium Alloy | 1.2''/40 mm | 6 bar | 35 m @ 6 bar | 110° |
| QLD6.0/1.0III-25 | Hard Anodized Aluminium Alloy | 2''/50 mm | 6 bar | 35 m @ 6 bar | 110° |
| QLD6.0/1.0III-25 | Hard Anodized Aluminium Alloy | 2.5''/65 mm | 6 bar | 35 m @ 6 bar | 110° |
Frequently Asked Questions
Frequently Asked Questions
Q. What about the lead time?
-
A:Sample needs 7-15 days, mass production time needs 30-40 weeks for order quantity more than 1 container.
Q. Do you have any MOQ limit?
-
A: For conventional products, Low MOQ, OEM products request 30-40days.
Q:What is your term and payment?
-
A:Payment<=5000USD, 100% in advance. Payment>=5000USD, 30% T/T in advance ,balance before shippment.
Q: Can I have a sample order?
-
A:Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q. Is it OK to OEM ?
-
A: Yes. Please inform us formally before our production and confirm the design and other requirements firstly .
Main Product:
Main Product:
Order Information
Order Information:
Dear Customer,
Before ordering, please contact with our sales team to discuss order information, such as Model Number, Flow Rate, Material, Control Ways, Package,Etc.
If you have any other requirements or wanna know more info about our products, welcome to contact as well. Our Sales team and Technical Department are willing to support you.
Hot Tags: fire spray nozzle 1inch, China, manufacturers, suppliers, wholesale, price, Fire Fighting Hoses Nozzles, Industrial Fire Hose Nozzles, Extended Coverage Sprinklers, Fire Nozzle With Pistol Grip, American Pistol Grip Fire Nozzle, 2 Inch Fire Hose Nozzle
Features
1).Flow Rate:15 - 30 - 45 - 60 LPM - Flush (Selectable).
2).Jetting Pattern: Straight stream,Narrow fog,Wide fog.
3).1/4 turn from straight stream to wide fog.
4).360° Swivel inlet, full time, even after tightening.
5).Compatible with Quick Attach Foam Tube.
6).Coupling standard: Storz,NH,INST,GOST,Machino,etc.
