Forestry Fire Nozzle
This manual nozzles calibrated at 6 bar, Contact the factory for data specific to models that operate with metric flow calibrations. QLD6.0/1.0III forestry fire nozzle is economical, lightweight, and dependable nozzles. Their rugged construction is compatible with the use of fresh water as well as firefighting foam concentrate. Other important operating features include:
• Quick-acting pattern control from straight stream to wide fog;
• Fixed fog teeth;
• Easily flushable while flowing to clear trapped debris;
• Quick-change fire hose coupling;
Technological Parameters
The details as following table:
| Model | Material | Inlet Size | Working Pressure | Max. Reach | Max. Fog Angle |
| QLD6.0/1.0III-25 | Hard Anodized Aluminium Alloy | 1''/25 mm | 6 bar | 35 m @ 6 bar | 110° |
| QLD6.0/1.0III-40 | Hard Anodized Aluminium Alloy | 1.5''/40 mm | 6 bar | 35 m @ 6 bar | 110° |
| QLD6.0/1.0III-50 | Hard Anodized Aluminium Alloy | 2''/50 mm | 6 bar | 35 m @ 6 bar | 110° |
| QLD6.0/1.0III-65 | Hard Anodized Aluminium Alloy | 2.5''/65 mm | 6 bar | 35 m @ 6 bar | 110° |
Detail Image
FAQ:
Q:Do you offer guarantee for the products?
A:Yes, we offer 1 year warranty to our products.
Q: How do you deliver the goods and how long does it take to arrive?
A:We usually deliver mass order by sea and air, delivery time is depended on the carrier,urgent trail order usually deliver by DHL, UPS, FedEx or TNT. It usually takes 5-7 days to arrive. Railway also optional. In fact, the delivery method depends on the quantity.
Q:Is it OK to OEM ?
A:A: Yes. Please inform us formally before our production and confirm the design and other requirements firstly .
Order Information:
Dear Customer,
Before ordering, please contact with our sales team to discuss order information, such as Model Number, Flow Rate, Material, Control Ways, Package,Etc.
If you have any other requirements or wanna know more info about our products, welcome to contact as well. Our Sales team and Technical Department are willing to support you.
Hot Tags: forestry fire nozzle, China, manufacturers, suppliers, wholesale, price, Fire Branches And Nozzles, Industrial Fire Hose Nozzles, Automatic Pistol Grip Nozzle, Fire Turbo Nozzle, American Pistol Grip Fire Nozzle, Fire Nozzle With Pistol Grip
1).Flow Rate:15 - 30 - 45 - 60 LPM - Flush (Selectable).
2).Jetting Pattern: Straight stream,Narrow fog,Wide fog.
3).1/4 turn from straight stream to wide fog.
4).360° Swivel inlet, full time, even after tightening.
5).Compatible with Quick Attach Foam Tube.
6).Coupling standard: Storz,NH,INST,GOST,Machino,etc.
