Name: China Bladder Tank Foam System For Fire Fighting Manufacturers, Suppliers - Wholesale Price - FOREDE
Brand: Forede
SKU: 202626666

Bladder Tank Foam System For Fire Fighting

Product Introduction:

The horizontal structure enhances the stability of the whole tank and effectively guarantees the safety of the fire foam tank. Large-capacity (generally more than three tons) fire-fighting foam tanks adopt a horizontal structure, which not only facilitates the transportation and installation of fire-fighting foam tanks, but also ensures higher safety

Send Inquiry

Description

Technical Parameters

Products Description

The bladder tank is a carbon steel pressure vessel, which stores a foam concentrate within an elastomeric bladder. The concentrate is discharged from the tank by incoming water applying pressure to the bladder. This applied energy is transferred to the concentrate, supplying pressurized concentrate to the proportioner .

Products Parameters

Model	Capacity	Style	W.Pressure	Ratio	Flow Rate
PHYM-1000	1000 Liters	Horizontal,fixed	0.8-1.2Mpa	3% or 6%	4-64LPS
PHYM-1500	1500 Liters	Horizontal,fixed	0.8-1.2Mpa	3% or 6%	4-64LPS
PHYM-2000	2000 Liters	Horizontal,fixed	0.8-1.2Mpa	3% or 6%	4-64LPS
PHYM-2500	2500 Liters	Horizontal,fixed	0.8-1.2Mpa	3% or 6%	4-64LPS
PHYM-3000	3000 Liters	Horizontal,fixed	0.8-1.2Mpa	3% or 6%	4-64LPS
PHYM-4000	4000 Liters	Horizontal,fixed	0.8-1.2Mpa	3% or 6%	4-64LPS
PHYM-5000	5000 Liters	Horizontal,fixed	0.8-1.2Mpa	3% or 6%	4-64LPS
PHYM-6000	6000 Liters	Horizontal,fixed	0.8-1.2Mpa	3% or 6%	4-64LPS
PHYM-8000	8000 Liters	Horizontal,fixed	0.8-1.2Mpa	3% or 6%	4-64LPS
PHYM-10000	10000 Liters	Horizontal,fixed	0.8-1.2Mpa	3% or 6%	4-64LPS

FAQ

1.Q: How To Order ?

A: Step 1, please tell us what model and quantity you need;

Step 2, then we will make a Pl for you to confirm the order details; Step 3, when we confirmedeverything, can arrange the payment; Step 4, finally we deliver the goods within the stipulated time.
