Products Description
Dust control water cannon
Forede Dust Control Water Cannon is a multi-functional manual spraying equipment independently developed for solving industrial dust pollution and vehicle cleaning problems. Different from electric spraying equipment, this product adopts a pure mechanical manual control mode, which gets rid of the limitation of power supply and can work stably in various complex and harsh working environments. The whole cannon is cast from high-strength stainless steel, which effectively solves common problems such as metal rust and inner wall abrasion caused by long-term contact with water and mineral dust. The product is equipped with a built-in flow regulating valve, realizing three-grade flow switching from 20LPS to 40LPS. Workers can select appropriate flow according to actual dust concentration and cleaning objects. Low flow is suitable for daily road watering, while high flow is applicable for intensive dust suppression and stubborn dirt cleaning of mining vehicles. The optimized internal flow channel greatly reduces water pressure loss, ensuring the water jet maintains stable pressure and longer spraying distance. The flexible rotating structure enables omnidirectional spraying without dead angles. The simple mechanical structure avoids complicated maintenance steps; users only need to drain residual water to prevent pipeline blockage. With great practicability and environmental adaptability, this stainless steel water cannon is widely promoted in mobile sprinkler vehicles and fixed dust control stations across multiple heavy industries.
Handle
Working Pressure
Adjustable Flow
Warranty
Specification
| Model Number | TFS1.AF020 | TFS1.AF030 | TFS1.AF040 | TFS1.AS040 |
| Flow Rate | 1200LPM | 1800LPM | 2400LPM | 1200-1800-2400LPM |
| Working Pressure | 8 bar | 8 bar | 8 bar | 8 bar |
| Max.Reach@8 bar | 50 Meters | 60 Meters | 65 Meters | 50-65Meters |
| Max.Fog Angle | 120° | |||
| Max Range of Motion |
-45° to +75° Vertically, 360° Rotation
|
|||
| Waterway Size | 2.5''(65mm) | |||
| Monitor Outlet |
2.5"(65mm) NH male thread
|
|||
| Monitor Inlet |
Flange 3" BS4504 is standard ( other sizes & standards are available )
|
|||
| Material |
Monitor - SS304 Stainless steel
Tiller - SS304 Stainless steel
Nozzle - Hard Anodized Aluminium Alloy
|
|||
Detail Pictures
Frequently Asked Question
Frequently Asked Questions
Q: What is a dust suppression water cannon?
-
A:forede Dust Control Water Cannon is a heavy-duty manual spray nozzle made of full stainless steel. It is commonly mounted on sprinkler trucks and fixed supports, designed for industrial dust elimination and vehicle cleaning. This manual nozzle supports three adjustable flow gears, allowing users to switch 20LPS, 30LPS and 40LPS freely to fit different cleaning and dust control scenarios.
Q. Advantages of dust suppression water cannon?
-
A: Adopting integrated stainless steel structure, this water cannon features outstanding rust resistance and abrasion resistance, adapting to harsh dusty outdoor environments. The all-mechanical design contains no electronic parts to reduce potential failures. It supports multi-direction manual rotation and three-speed flow adjustment to balance spraying range and working efficiency.
Q. Why Choose dust suppression water cannon?
-
A: forede manual water cannon boasts robust overall structure to withstand water hammer pressure during long-term high-frequency use. The finely polished inner pipeline reduces water resistance and delivers concentrated straight water jets. Simple manual flow and angle adjustment lowers operation difficulty, and its maintenance-free structure helps cut overall operating costs.
Q. Where to Use dust suppression water cannon?
-
A: It is mainly used for open-pit mines and quarries to suppress floating dust and clean mining dump trucks. It can be installed on sprinkler vehicles for road humidity maintenance. It also covers bulk material yards, large construction sites and industrial zones for daily watering and equipment cleaning work.
Q. How to Use dust suppression water cannon?
-
A: Install and fix the water cannon on qualified base, then complete pipeline connection and check tightness. Turn on the water supply system, manually adjust the flow regulator to 20LPS, 30LPS or 40LPS. Adjust horizontal and vertical angles to finish cleaning and dust control work. Drain internal residual water after daily operation.
