Fire System Monitoring Companies

Product Introduction:

In conclusion, the Firefighting Automatic Monitor is a highly effective tool that is transforming the way we fight fires. Its automatic and early detection capabilities, coupled with its ability to prevent fires from spreading and save lives, make it an essential component of modern firefighting. As this technology becomes more widespread, it will undoubtedly help to reduce the damage and destruction caused by fires and keep people and property safe.

Send Inquiry

Description

Technical Parameters

Products Description

Feature

Hard anodized aluminum alloy construction;
Laser positioning indication, high-definition screen monitoring;
Straight stream & Fog or Straight stream nozzle;
Vertical travel of 120°,from -90° to +30°;
360° rotation horizontally;
Electric control jetting pattern: Straight stream,Fog;
Electric.driver and control unit box are waterproof;
Optional power supply 220V AC.

Model	ZDMS0.8 /20S-W	ZDMS0.8 /30S-W
Working Pressure	8 bar
Flow Rate	1200 LPM	1800 LPM
Jetting Radius	56 m	62 m
Monitoring Radius	80 m
Max Protection Radius	50 m	55 m
Mounting Height	8~15 m
Targeting Time	≤60 S
Swing Horizontally	360°
Elevate Vertically	-90° to +30°
Inlet	2" BS Flange, others size and standard available
Detector Type	Infrared ray&UV sensor technology
Communication Mode	RS485
Power Consumption	Monitoring 1W, Detecting 50W

FC1JYL0ZDT3LG75POG

Products Question

ZDMS20-30-W

Q. Do your offer free sample for your clients?

A: Yes, we offer free sample for many of the products

Q. What's the MOQ of your products?

A: Our MOQ is one (1) piece/set.

Q. What's your payment terms?

A: We accept T/T, L/C, Western Union, Paypal,etc.

Q. How long is the delivery time?

A: Usually around 15 days after payment.

Order Information

Dear Customer,

Before ordering, please contact with our sales team to discuss order information, such as Model Number, Flow Rate, Material, Control Ways, Package,Etc.

If you have any other requirements or wanna know more info about our products, welcome to contact as well. Our Sales team and Technical Department are willing to support you.
