FOREDE Automatic Fire Monitor

FOREDE Automatic Fire Monitor
Product Introduction:
ZDMS0.8/S-W FOREDE Automatic Fire Monitor has the advantages of wide application range, easy operation, fast response speed and good fire extinguishing effect. Compared with traditional manual fire extinguishing methods, the response speed of the FOREDE Automatic Fire Monitor is faster because it can detect the fire in time and carry out corresponding fire extinguishing operations. At the same time, the FOREDE Automatic Fire Monitor does not require manual operation, reducing the risks to workers and improving the safety factor.
Send Inquiry
Description
Technical Parameters
Products Description















FOREDE Automatic Fire Monitor

The FOREDE Automatic Fire Monitor is a modern fire-fighting equipment that can use advanced technology to greatly improve the efficiency of fire extinguishing and effectively prevent the occurrence of fires.



This kind of FOREDE Automatic Fire Monitor can realize fast and accurate fire source positioning, and can also be automatically controlled to achieve fire extinguishing. At the fire scene, the fire extinguishing equipment will automatically detect information such as ambient temperature, smoke concentration, and flame, and automatically start the fire extinguishing equipment.



There are many advantages to self-seeking fire extinguishing devices. First, it can automatically search for fire sources and start fire extinguishing equipment immediately after discovering fire sources. Secondly, it can extinguish fires in the early stages of fires, prevent the spread of fires, and reduce losses caused by fires. In addition, it can promptly notify the fire rescue department and help rescue personnel achieve rapid response. Most importantly, this equipment protects people's lives and property.



In short, the FOREDE Automatic Fire Monitor is a very important fire-fighting equipment. It adopts advanced technology to improve the efficiency of fire extinguishing, prevent the occurrence of fires, and protect people's lives and property safety.

12

Aluminum Alloy
Material
Auto/Wireless/ Manual
Control Way
SS/ Fog
Spray Pattern
Water/ Foam
Medium
Technical Parameter
Model
ZDMS0.8/ 20S-W
ZDMS0.8/ 30S-W

Flow Rate

1200 LPM

1800 LPM

Working Pressure

8 Bar 8 Bar

Jetting radius

56 meters

62 meters

Max protection radius 50 meters 55 meters
Monitoring radius 80 meters 80 meters

Installation Height

advice 8-15m
tartgeting time ≤60 S

Max Range Of Motion

-90° to +30° Vertically, 360° Rotation

Power supply AC 220V is standard

Waterway Size

2.5'' (65mm)

Monitor Outlet

2.5'' nH male thread

Monitor Inlet

Flange 4" BS4504 is standard ( other sizes & standards are available )

Material

Monitor & Nozzle - Hard coated anodized aluminium alloy

Detector type infrared ray & uV sensor
Communication Mode RS485



FAQ

Q: What's the MOQ?

A: MOQ=1 Set

Q: What's the price?

A: Email to sales1@forede.com or call to 0086 13107856309 ( same whatsApp), or Wechat: 13107856309

Q: What's the production time?

A: Based on quantity, generally 15-20 days.

Q: What's the product brand? OEM available?

A: " forede " brand and OEM available, please specify when ordered.

Q: Where is the " FOREDE " from?

A: It's Chinese Brand original.

Q: How long the warranty time?

A: 12 months from starting installation

Q: Can we buy spare parts in the future for replacement?

A: " forede " is doing a long-term bussiness with customers, will always offer after-sales service.

Q: What's the products certification?

A: ISO and CE
