Firefighter Fixed Water Cannon

Firefighter Fixed Water Cannon
Product Introduction:
The Firefighter Fixed Water Cannon is an essential tool for firefighters and rescue teams. With its impressive flow rate of 1200 LPM up to 3000 LPM and working pressure of 10 Bar, this water cannon can effectively control and extinguish a wide range of fires.
Send Inquiry
Description
Technical Parameters




Products Description



Fixed Manual Fire Monitors-Firefighter Fixed Water Cannon

The maximum reach of this water cannon at 10 Bar is 70 meters, which means it can be used to put out fires in tall buildings, factories, or other high-stress environments. Additionally, the monitor outlet is 2.5" (65mm) NH male thread, which provides a steady and powerful flow of water.



One of the key features of this water cannon is its ability to rotate 360° horizontally and have a range of -45° to +90° vertically. This means the water cannon can be aimed at any angle to tackle fires from various directions.



The material used to manufacture the Firefighter Fixed Water Cannon is high-quality hard-coated anodized aluminium alloy, making it durable and resistant to corrosion. The handwheel is also made up of aluminium or ductile iron, providing a firm grip that allows for easy adjustment of the nozzle.

  • 1
    Fixed Manual Fire Monitors-Firefighter Fixed Water Cannon
  • 1
    Fixed Manual Fire Monitors-Firefighter Fixed Water Cannon
  • 1
    Fixed Manual Fire Monitors-Firefighter Fixed Water Cannon
  • 1
    Fixed Manual Fire Monitors-Firefighter Fixed Water Cannon

Products Detailed
product-1148-595
Angle
product-1148-595
Part Name

Technical Parameter

What Is The Significance Of The Max Range Of Fire Fixed Water Cannon?



The Max Range of fire Fixed Water Cannon is an important feature that has significant implications for fire suppression and control. This feature refers to the maximum distance that the fixed water cannon can spray water, and its importance lies in its ability to effectively reach and extinguish fires that may be out of reach of traditional firefighting methods.



By virtue of its long range, the Max Range of fire Fixed Water Cannon can provide firefighters with an invaluable tool in their efforts to suppress fires. This feature allows firefighters to direct a powerful stream of water at flames from a safe distance, giving them greater control over the spread of fire and reducing the risk of injury or death.



Moreover, the Max Range of fire Fixed Water Cannon is also useful in situations where reaching the fire is particularly difficult, such as in high-rise buildings, enclosed spaces, or densely populated areas. In these situations, the range of the water cannon can be critical in suppressing the flames and preventing further damage or loss of life.

Model Number

PS10/20-50-H

Flow Rate

1200 LPM up to 3000 LPM

Working Pressure

10 Bar

Max. Reach @ 10 bar

70 meters @ 3000 LPM

Max Range Of Monitor

-45° to +90° Vertically, 360° Rotation

Waterway Size

2.5"(65mm)

Monitor Outlet

2.5" (65mm) NH male thread

Monitor Inlet

Flange 4" BS4504 is standard ( other sizes & standards are available )

Material

Monitor & Nozzle - Hard coated anodized aluminium alloy

Handwheel - Aluminium or Ductile Iron


Application Area




QQ20240401145245

Rescue Services

22

Residential Buildings



33

Industrial Settings

44

Public Space


Frequently Asked Questions

Q: Can I choose the specifications of the fire monitor?

A: You can choose according to your needs.

Q: How to Use Fire Monitor?

A: 1. Connect the Monitor 2. Position the Monitor 3. Adjust the Flow 4. Aim the Nozzle 5. Monitor the Fire

Q: Can the Monitor Head of the Fire Monitor Be Replaced?

A: Yes, ensure that the fire equipment is fully operational only,the monitor head of a fire monitor can be replaced.

Q: What Are the Flange Standards for Fire Monitors?

A: The most commonly used flange standards for fire monitors include BS4504, ANSI150, GB, etc.

Products Workshop




-

FIRE

           NOZZLES

-

FIRE

MONITORS

DSC10720

FOAM

CONCENTRATE

product-377-307

GENERAL

VALVE




Order steps



1

Determine parameters

Confirm the production details of the order with sales staff.

2

Place order

Pay a deposit or full payment.

3

Production

After payment, we arrange production

4

 Shipment

Confirm the shipping address and shipping fee, then you can ship the goods.



forede® Main Products

How to contact us?
How To Cooperate With Us?

Our address

Nan'an City, Quanzhou City Fujian PRC-china

Phone Number

2





Hot Tags: Firefighter Fixed Water Cannon, China, manufacturers, suppliers, wholesale, price, Portable Ground Fire Monitor, Remote Operated Fire Water Monitors, Deluge Valve For Sprinkler System, Fog Spike Nozzle With Pistol, Remote Control Ground Fire Water Monitor, Straight Landing Valve Flange End



Features:

Aluminium alloy construction,hard coated anodized;

Flow Rate: 20-50 LPS (Stacked Tips Adjustable);

Jetting Pattern: Straight stream;

Flange standard: BS4504,ANSI150,GB,etc.

.
