Handwheel Control Manual Foam Monitor
Handwheel control manual foam monitor is manual control with one handwheel to change the vertical swing and another for horizontal rotation.
The specification of this handwheel control manual foam monitor as following:
Flow rate : 1440LPM-1920LPM-2880LPM, with a foam nozzle, the flow rate is constant.
Foam expansion times: over 6 times. Good for foam expansion. This nozzle can be used for water and foam concentrate.
Working pressure of handwheel control manual foam monitor is 8 Bar, and the max. Jetting range of this monitor can reach 65 meters at 2880LPM.
The vertical motion range of handwheel control manual foam monitor can reach -45° to +90°,and the horizontal rotaion of this foam monitor is 360°. Of course, the motion range is changable, the angle can change for your demand.
The outlet size is 2.5" NH female/male thread, the inlet is 3" flange, flange standards have BS4504,ANSI150,GB,etc.
Handwheel control manual foam monitor is an total hard coated anodized aluminium alloy construction.
Model | PL8/24-B | PL8/32-B | PL8/48-B |
Flow Rate | 1440 LPM | 1920 LPM | 2880 LPM |
Working pressure | 8 Bar | 8 Bar | 8 Bar |
Foam Jetting Range | 45 meters | 55 meters | 65 meters |
Water Jetting Range | 40 meters | 50 meters | 60 meters |
Foam Expansion | ≧ 6 times | ≧ 6 times | ≧ 6 times |
Rotation Horizontally | 360° | 360° | 360° |
Elevate Vertically | -45° to +90° | -45° to +90° | -45° to +90° |
Inlet | DN80 (3") | DN80 (3") | DN80 (3") |
Outlet | 2.5" NH | 2.5" NH | 2.5" NH |
Main Product:
FAQ:
Q: What is your term and payment?
Payment<=5000USD, 100% in advance. Payment>=5000USD, 30% T/T in advance ,balance before shippment.
Q:Do you have any MOQ limit?
For conventional products, Low MOQ, OEM products request 30-40days.
Order Information:
Dear Customer,
Before ordering, please contact with our sales team to discuss order information, such as Model Number, Flow Rate, Material, Control Ways, Package,Etc.
If you have any other requirements or wanna know more info about our products, welcome to contact as well. Our Sales team and Technical Department are willing to support you.
Hot Tags: handwheel control manual foam monitor, China, manufacturers, suppliers, wholesale, price, Multi Purpose Fire Nozzles, Elevated Fire Water Monitor, Fire Truck Monitor, Automatic Fire Monitor, Foam Monitor System Design, Anti Riot Water Cannon
1) Aluminium alloy construction;
2) Handwheel Control;
3) Flow Rate: 24/32/48 LPS (optional);
4) Available for water and foam both;
5) 360° rotation horizontally;
6) -45° to +90° elevate vertically;
7) Flange standard: BS4504,ANSI150,GB,etc.
